SolaX Power TBMS-MCS0800 User Manual

16
3 Production Information
3.5.2 T-BAT-SYS-HV-S36
■
Configuration List
No. Module BMS
Battery
Module
Nominal
Energy
(kWh)
Operating
Voltage
(Vdc)
1 T-BAT HS7.2 TBMS-MCS0800 × 1 TP-HS36 × 2 7.37 90-116
2 T-BAT HS10.8 TBMS-MCS0800 × 1 TP-HS36 × 3 11.06 135-174
3 T-BAT HS14.4 TBMS-MCS0800 × 1 TP-HS36 × 4 14.75 180-232
4 T-BAT HS18.0 TBMS-MCS0800 × 1 TP-HS36 × 5 18.43 225-290
5 T-BAT HS21.6 TBMS-MCS0800 × 1 TP-HS36 × 6 22.12 280-349
6 T-BAT HS25.2 TBMS-MCS0800 × 1 TP-HS36 × 7 25.80 315-406
7 T-BAT HS28.8 TBMS-MCS0800 × 1 TP-HS36 × 8 29.49 360-465
8 T-BAT HS32.4 TBMS-MCS0800 × 1 TP-HS36 × 9 33.18 405-522
9 T-BAT HS36.0 TBMS-MCS0800 × 1 TP-HS36 × 10 36.86 450-580
10 T-BAT HS39.6 TBMS-MCS0800 × 1 TP-HS36 × 11 40.55 495-636
11 T-BAT HS43.2 TBMS-MCS0800 × 1 TP-HS36 × 12 44.24 540-695
12 T-BAT HS46.8 TBMS-MCS0800 × 1 TP-HS36 × 13 47.92 585-750
■
Performance
Module T-BAT HS7.2 T-BAT HS10.8 T-BAT HS14.4 T-BAT HS18.0 T-BAT HS21.6 T-BAT HS25.2
Nominal Voltage (Vdc) 102.4 153.6 204.8 256 307.2 358.4
Operating Voltage (Vdc) 90-116 135-174 180-232 225-290 270-349 315-406
Nominal Capacity (Ah)  72 72 72 72 72 72
Nominal Energy (kWh)  7.37 11.06 14.75 18.43 22.12 25.80
Usable Energy 90% DOD
(kWh) 
6.6 10.0 13.3 16.6 19.9 23.2
Max. Charge/Discharge
Current (A) 
50 50 50 50 50 50
Recommend Charge/Dis-
charge Current (A) 
50 50 50 50 50 50
Standard Power (kW) 3.58 5.38 7.17 8.96 10.75 12.54
Max. Power (kW) 5.12 7.68 10.24 12.8 15.36 17.92
Short-circuit Current (A) 1850 1850 1850 1850 1850 1850
Battery Round-trip Effi-
ciency (0.2 C, 25°C)
95%
Expected Lifetime (25°C) 10 years
Cycle Life 90% DOD (25°C) 6000 cycles
Charge Temperature 0°C ~ 53°C 
Discharge Temperature -20°C ~ 53°C 
Storage Temperature
-20°C ~ 53°C (3 months)
10°C ~ 40°C (1 year)
Ingress Protection IP65
Protection Class I
Continued on the next page
