3 Production Information
Module T-BAT HS20.0 T-BAT HS22.2 T-BAT HS25.0 T-BAT HS27.5 T-BAT HS30.0 T-BAT HS32.5
Nominal Voltage (Vdc) 409.6 460.8 512 563.2 614.4 665.6
Operating Voltage (Vdc) 360-465 450-522 450-480 495-636 540-695 585-750
Nominal Capacity (Ah) 50 50 50 50 50 50
Nominal Energy (kWh) 20.48 23.04 25.60 28.16 30.72 33.28
Usable Energy 90% DOD
(kWh)
18.4 20.7 23.0 25.3 27.6 30.0
Max. Charge/Discharge
Current (A)
50 50 50 50 50 50
Recommend Charge/
Discharge Current (A)
50 50 50 50 50 50
Standard Power (kW) 12.3 13.8 15.4 16.9 18.4 20.0
Max. Power (kW) 18.432 20.736 23.04 25.344 27.648 29.952
Short-circuit Current (A) 1900 1900 1900 1900 1900 1900
Battery Round-trip Effi-
ciency (0.2 C, 25°C)
95%
Expected Lifetime (25°C
)
10 years
Cycle Life 90% DOD
(25°C)
6000 cycles
Charge Temperature 0°C ~ 53°C
Discharge Temperature -20°C ~ 53°C
Storage Temperature
-20°C ~ 53°C (3 months)
10°C ~ 40°C (1 year)
Ingress Protection IP65
Protection Class I
*Note:
1.
Test conditions: 100% DOD, 0.2 C charge & discharge @ +25°C.
2.
90% DOD; System usable energy may vary with inverter different setting.
3.
Discharge: In case of battery cell’s temperature range of -20°C~10°C and
45°C~53°C, the discharge current will be reduced; Charge: In case of battery
cell’s temperature range of 0°C~25°C and 45°C~53°C, the charge current will be
reduced. Product charge or discharge power depends on the actual temperature
of battery pack.
4.
The battery can only be discharged and cannot be charged at the range of
from -20°C to 0°C.
5.
In case of a rated current of 30 A, the wire size of 10 AWG for cables (including
grounding cable) is recommended; in case of a rated current of 45 A, the wire
size of 8 AWG for cables (including grounding cable) is recommend.
6.
In the allowable range, the relative humidity range should be between 5%
and 95% RH. In the meantime, effective measures should be taken to prevent
condensation.
