1 Note on this Manual

1.1 Scope of Validity

This manual, an integral part of T-BAT Series, contains information on assembly,

commissioning, maintenance and failure of the device. Please read it carefully

before operation.

BMS

TBMS-MCS0800

Battery Module

TP-HS25, TP-HS36

Note: In case of one group, there are 3 parts of the T-BAT system, which includes

BMS, battery module(s) and base. In case of two groups, there 4 parts of the

system, such as, BMS, battery module(s), base and Series Box. For details, please

refer to 3.3.1 Configuration List on page.

1.2 Target Group

This Manual is designed for qualified electricians. The installation procedure

described in the Manual may only be performed by qualified electricians.

1.3 Symbols

There are several safety marks in the Manual. The detailed explanation is shown

as follows:

DANGER!

“DANGER” indicates a hazardous situation which, if not avoided, will

result in serious injury or death.

WARNING!

“WARNING“ indicates a hazardous situation which, if not avoided, could

result in serious injury or death.

CAUTION!

“CAUTION“ indicates a hazardous situation which, if not avoided, could

result in minor or moderate injury or death.

NOTE!

“NOTE“ indicates that tips will be given to achieve better using effect.

SolaX Power TBMS-MCS0800 User Manual
