SolaX Power X1-Fit-3.7C User Manual

1.1 Scope of Validity
This manual is an integral part of X1-Retro Fit, It describes the assembly,
installation, commissioning, maintenance and failure of the product. Please read it
carefully before operating.
Note: “3.7” means 3.7kW.
“E” means “EPS function” will be available with an external changeover
device installed.
“I” means “EPS function” available as unit already content an internal
changeover device.
“C “means without”EPS function”.
Store this manual where it will be accessible at all times.
1.2 Target Group
This manual is for qualified electricians. The tasks described in this manual only
can be performed by qualified electricians.
1.3 Symbols Used
The following types of safety instructions and general information appear in this
document as described below:
1 Notes on this Manual
Notes on this ManualContents
Danger！
“Danger” indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
Warning!
“Warning” indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
Caution！
“Caution” indicates a hazardous situation which, if not avoided, could result
in minor or moderate injury.
Note！
“Note” provides tips that are valuable for the optimal operation of our
product.
X1-Fit-3.7E
X1-Fit-3.7I
X1-Fit-3.7C
X1-Fit-4.6E
X1-Fit-4.6I
X1-Fit-4.6C
X1-Fit-5.0I
X1-Fit-5.0E
X1-Fit-5.0C
03
8. Setting
8.1 Control Panel
8.2 Menu Structure
8.3 LCD Operation
9 Troubleshooting
9.1 Trouble Shooting
9.2 Routine Maintenance
10 Decommissioning
Dismantling the Inverter10.1
Packaging10.2
Storage and Transportation10.3
42
42
43
44
6.5 Meter Connection
6.6 LAN Connection
6.7 DRM Connection
6.8 WiFi Connection(optional)
6.9 RF Connection(optional)
6.10 Inverter Manipulation
32
34
35
36
37
38
7. Firmware Upgrading
40
62
62
66
67
67
67
67
02

SolaX Power X1-Fit-3.7C Specifications

General

Brand	SolaX Power
Model	X1-Fit-3.7C
Category	Inverter
Language	English
