8.3 LCD Operation
● Status
The status function contains four items of the inverter: grid, charger, eps and
Load.
Press up and down to select and press “OK” to confirm the selection, press “ESC”
to return to Menu.
a) Grid
This status shows the current grid condition such as voltage, current, output
power and the local consumed power.
Pout measures the output of the inverter;
Pgrid measures power export to or import from grid.
Positive value means the energy feeds into grid, negative value means the
energy used from the grid.
LCD Digital Display
The main interface is the default interface, the inverter will automatically jump to
this interface when the system started up successfully or not operated for a
period of time.
The information of the interface is as below. “Power” means the instant output
power; “Today” means the power generated within the day. “Battery” means the
left capacity of battery energy.
Power 0W
Today 0.0KWh
Battery %
Normal
Status
History
Settings
Menu
Menu interface
The menu interface is a transfer interface for user to get into another interface
to change the setting or getting the information.
-User can get into this interface by pressing “OK” button when LCD displays the
main interface.
-User can select interface by moving the cursor with function button，and press
“OK” to confirm.
Menu
Status
History
Setting
System Switch
About
Status
Grid
Load
EPS
Charger
Ø
Status
Grid
Charger
EPS
Status
U 000.0V
I 00.0A
P 00.0W
Grid
44
45
Setting Setting
b) Charger
This status shows the charger situation of the system. Include the battery
voltage, charge or discharge current. Charge or discharge power, battery
capacity and battery temperature. “+” means in charging; “-” means in
discharging.
U 100.0V
I +1.0A
P +100W
Charger
