Operation on LCD
NOTICE!
• CT and meter 1 can not be used simutaneously.
====CT/MeterSetting====
>Select
Meter
====CT/MeterSetting====
>Select
Enable
====CT/MeterSetting====
>Meter 1 Addr
1
====CT/MeterSetting====
>Meter 1 Direction
Positive
»
Case 3: CT and Meter 2 are connected. (CT for SolaX Hybrid inverter,
Meter 2 for another power generation equipment or CT for another power
generation equipment, Meter 2 for SolaX Hybrid inverter) For CT setting,
please refer to Case 1. For meter 2 setting, please set the address and
direction of Meter 2 based on actual connection and Enable the External
INV. You can check the connection status in Meter/CT Check.
====CT/MeterSetting====
>Meter 2 Addr
1
====CT/MeterSetting====
>Meter 2 Direction
Positive
====CT/MeterSetting====
>External INV
Enable
»
Case 4: Meter 1 and Meter 2 are connected. (Meter 1 for SolaX Hybrid
inverter, Meter 2 for another power generation equipment or Meter 1 for
another power generation equipment, Meter 2 for SolaX Hybrid inverter).
Please refer to Case 2 for Meter 1 setting and Case 3 for Meter 2 setting. You
can check the connection status in Meter/CT Check.
Setting Self Test (only for CEI 0-21)
The self test function allows users to test the following items: Full Test, Ovp(59.S2) test.
Uvp (s1) test, Uvp (27. s2) test, Ofp (81> .S1) test, Ufp (81 <.S1) test, Ufp (81> .S2) test, Ufp (81
<.S2) test, Ovp10 (59. s1) test.
In the Self Test interface, the user can select All Test or a single test item for testing. All
tests take about 6 minutes. And it will display Success. For a single test item, it takes about
a few seconds or minutes.
Before testing, make sure that the inverter is connected to the grid. Click Test Report to
view the test results of all items.
======Self Test======
>All Test
Test Report
Ovp (59.S2) test
Setting GMPPT
You can set the shadow tracking speed with four options, which are Off, Low, Middle, and
High. This function is off by default.
