Solax X1 Series User Manual

1) The first line displays the parameters(Power, Pgrid, Today and Total) and
the values.
LCD Display
Ø
Power 0W
Normal
Today 0.0kWh
Normal
Total 0.0kWh
Normal
Pgrid 0W
Normal
>Status
Language
Menu
>Grid
Solar
Status
• Level 1
2) The second line shows the running status.
“Normal” means the running status of the inverter.
• Level 2
Long press the “Enter” button to enter the second-level interface.
User can see parameters, such as the Status, Language, Date Time,
Settings (need password ), Meter energy (including Total Import, Total
Export), Error Logs (of the inverter), and About ( the user can browse the
information of the inverter, including product serial number, machine type,
register sn, master, slave, manager and internal code).
a) Status
The status function contains two aspects: the grid and the solar.
Press “Up“ and “Down” to select and long press “down” to confirm the
selection, long press “Up” to return to Menu.
64
>U
I
Grid
1) Grid
This status shows the current condition of the AC output port of the
inverter, such as voltage, current, output power and grid power.
This status includes 5 parameters: U, I, F, Pout, Pgrid.
Press “Up“ and “Down” to select and long press “down” to confirm the
selection, long press “Up” to return.
2) Solar
This status shows the real time PV condition of the system, such as
input voltage, current and power situation of each PV input.
This status includes 6 parameters: U1, I1,P1.
Press “Up“ and “Down” to select and long press “down” to confirm the
selection, long press “Up” to return
0.0V
0.0A
>U1
I1
Solar
0.0V
0.0A
b) Language
Users can select a language from English, German, Polish, French,
Portuguese, Chinese, Spanish, Italian and Dutch by this function.
>English
German
Language
c) Date Time
This interface is for the user to set the system date and time. Increase or
decrease the word by pressing “Up” or “Down” button. Long press “Down”
65
Parameter
Meaning
Power
Pgrid
The power export to or import from the grid; (Positive value means the energy feeds
into grid, negative value means the energy used from the grid).
Today
The power generated within the day.
Total
The power generated in total.
The output power of inverter.
1) The first line displays the parameters(Power, Pgrid, Today and Total) and
the values.
LCD Display
Ø
Power 0W
Normal
Today 0.0kWh
Normal
Total 0.0kWh
Normal
Pgrid 0W
Normal
>Status
Language
Menu
• Level 1
2) The second line shows the running status.
“Normal” means the running status of the inverter.
• Level 2
Long press the “Enter” button to enter the second-level interface.
User can see parameters, such as the Status, Language, Date Time,
Settings (need password ), Meter energy (including Total Import, Total
Export), Error Logs (of the inverter), and About ( the user can browse the
information of the inverter, including product serial number, machine type,
register sn, master, slave, manager and internal code).
a) Status
The status function contains two aspects: the grid and the solar.
Press “Up“ and “Down” to select and long press “down” to confirm the
selection, long press “Up” to return to Menu.
54
Parameter
Meaning
Power
Pgrid
The power export to or import from the grid; (Positive value means the energy feeds
into grid, negative value means the energy used from the grid).
Today
The power generated within the day.
Total
The power generated in total.
The output power of inverter.
>Grid
Solar
Status
>U
I
Grid
1) Grid
This status shows the current condition of the AC output port of the
inverter, such as voltage, current, output power and grid power.
Press ”Up“ and “Down” button to review the parameter, long press “up” to
return to Status .
2) Solar
This status shows the real time PV condition of the system, such as
input voltage, current and power situation of each PV input.
Press ”Up“ and “Down” button to review parameter, long Press “Up” to
return to Status.
0.0V
0.0A
>U1
I1
Solar
0.0V
0.0A
b) Language
The function refers to select a language from English, German, Polish, French,
Portuguese, etc.
>English
German
Language
c) Date Time
This interface is for the user to set the system date and time. Increase or
decrease the word by pressing “Up” or “Down” button. Press “Down” to
confirm and alternate to next word. After all the words are confirmed. Long
press “Down” to enter the date and time.

Solax X1 Series Specifications

General

Number of MPPTs	2
Protection Rating	IP65
Max. DC Voltage	550V
Max. PV Input Voltage	550V
Max. PV Input Power	6000W
Max. Input Current	11A
Rated Output Power	5000W
Max. Output Power	5500W
Nominal Output Voltage	230V
Output Frequency	50Hz/60Hz
European Efficiency	97.0%
Weight	18kg
Operating Temperature	-25°C to 60°C
Cooling	Natural
Communication	WiFi
