Solid State Logic ORIGIN Installation Guide

ORIGIN Installation Guide
Making Connections
21
LF (Large Fader) Insert Sends
25 Way F D-type Patch Patch Patch Patch
Cct# Hot Cold Scrn LF Ins Snd 1-8 Ref** LF Ins Snd 9-16 Ref** LF Ins Snd 17-24 Ref** LF Ins Snd 25-32 Ref**
1 24 12 25 LF Ins Snd 1
G1
LF Ins Snd 9
G9
LF Ins Snd 17
G17
LF Ins Snd 25
G25
2 10 23 11 LF Ins Snd 2
G2
LF Ins Snd 10
G10
LF Ins Snd 18
G18
LF Ins Snd 26
G26
3 21 9 22 LF Ins Snd 3
G3
LF Ins Snd 11
G11
LF Ins Snd 19
G19
LF Ins Snd 27
G27
4 7 20 8 LF Ins Snd 4
G4
LF Ins Snd 12
G12
LF Ins Snd 20
G20
LF Ins Snd 28
G28
5 18 6 19 LF Ins Snd 5
G5
LF Ins Snd 13
G13
LF Ins Snd 21
G21
LF Ins Snd 29
G29
6 4 17 5 LF Ins Snd 6
G6
LF Ins Snd 14
G14
LF Ins Snd 22
G22
LF Ins Snd 30
G30
7 15 3 16 LF Ins Snd 7
G7
LF Ins Snd 15
G15
LF Ins Snd 23
G23
LF Ins Snd 31
G31
8 1 14 2 LF Ins Snd 8
G8
LF Ins Snd 16
G16
LF Ins Snd 24
G24
LF Ins Snd 32
G32
LF (Large Fader) Insert Returns
25 Way F D-type Patch Patch Patch Patch
Cct# Hot Cold Scrn LF Ins Rtn 1-8 Ref** LF Ins Rtn 9-16 Ref** LF Ins Rtn 17-24 Ref** LF Ins Rtn 25-32 Ref**
1 24 12 25 LF Ins Rtn 1
H1
LF Ins Rtn 9
H9
LF Ins Rtn 17
H17
LF Ins Rtn 25
H25
2 10 23 11 LF Ins Rtn 2
H2
LF Ins Rtn 10
H10
LF Ins Rtn 18
H18
LF Ins Rtn 26
H26
3 21 9 22 LF Ins Rtn 3
H3
LF Ins Rtn 11
H11
LF Ins Rtn 19
H19
LF Ins Rtn 27
H27
4 7 20 8 LF Ins Rtn 4
H4
LF Ins Rtn 12
H12
LF Ins Rtn 20
H20
LF Ins Rtn 28
H28
5 18 6 19 LF Ins Rtn 5
H5
LF Ins Rtn 13
H13
LF Ins Rtn 21
H21
LF Ins Rtn 29
H29
6 4 17 5 LF Ins Rtn 6
H6
LF Ins Rtn 14
H14
LF Ins Rtn 22
H22
LF Ins Rtn 30
H30
7 15 3 16 LF Ins Rtn 7
H7
LF Ins Rtn 15
H15
LF Ins Rtn 23
H23
LF Ins Rtn 31
H31
8 1 14 2 LF Ins Rtn 8
H8
LF Ins Rtn 16
H16
LF Ins Rtn 24
H24
LF Ins Rtn 32
H32
SF (Small Fader) Insert Sends
25 Way F D-type Patch Patch Patch Patch
Cct# Hot Cold Scrn SF Ins Snd 1-8 Ref** SF Ins Snd 9-16 Ref** SF Ins Snd 17-24 Ref** SF Ins Snd 25-32 Ref**
1 24 12 25 SF Ins Snd 1
I1
SF Ins Snd 9
I9
SF Ins Snd 17
I17
SF Ins Snd 25
I25
2 10 23 11 SF Ins Snd 2
I2
SF Ins Snd 10
I10
SF Ins Snd 18
I18
SF Ins Snd 26
I26
3 21 9 22 SF Ins Snd 3
I3
SF Ins Snd 11
I11
SF Ins Snd 19
I19
SF Ins Snd 27
I27
4 7 20 8 SF Ins Snd 4
I4
SF Ins Snd 12
I12
SF Ins Snd 20
I20
SF Ins Snd 28
I28
5 18 6 19 SF Ins Snd 5
I5
SF Ins Snd 13
I13
SF Ins Snd 21
I21
SF Ins Snd 29
I29
6 4 17 5 SF Ins Snd 6
I6
SF Ins Snd 14
I14
SF Ins Snd 22
I22
SF Ins Snd 30
I30
7 15 3 16 SF Ins Snd 7
I7
SF Ins Snd 15
I15
SF Ins Snd 23
I23
SF Ins Snd 31
I31
8 1 14 2 SF Ins Snd 8
I8
SF Ins Snd 16
I16
SF Ins Snd 24
I24
SF Ins Snd 32
I32
Channel DB-25 Pinouts cont'd
**NOTE: Patch Reference on following tables only applies if using suggested standard patch layout on Page 26
Mon (Monitor) Path Line Inputs
25 Way F D-type Patch Patch Patch Patch
Cct# Hot Cold Scrn Mon Line IN 1-8 Ref** Mon Line IN 9-16 Ref** Mon Line IN 17-24 Ref** Mon Line IN 25-32 Ref**
1 24 12 25 Mon Line IP 1
F1
Mon Line IP 9
F9
Mon Line IP 17
F17
Mon Line IP 25
F25
2 10 23 11 Mon Line IP 2
F2
Mon Line IP 10
F10
Mon Line IP 18
F18
Mon Line IP 26
F26
3 21 9 22 Mon Line IP 3
F3
Mon Line IP 11
F11
Mon Line IP 19
F19
Mon Line IP 27
F27
4 7 20 8 Mon Line IP 4
F4
Mon Line IP 12
F12
Mon Line IP 20
F20
Mon Line IP 28
F28
5 18 6 19 Mon Line IP 5
F5
Mon Line IP 13
F13
Mon Line IP 21
F21
Mon Line IP 29
F29
6 4 17 5 Mon Line IP 6
F6
Mon Line IP 14
F14
Mon Line IP 22
F22
Mon Line IP 30
F30
7 15 3 16 Mon Line IP 7
F7
Mon Line IP 15
F15
Mon Line IP 23
F23
Mon Line IP 31
F31
8 1 14 2 Mon Line IP 8
F8
Mon Line IP 16
F16
Mon Line IP 24
F24
Mon Line IP 32
F32
