Solid State Logic ORIGIN Installation Guide

ORIGIN Installation Guide
Making Connections
24
Master Section DB-25 Pinouts Cont'd
**NOTE: Patch Reference on following tables only applies if using suggested standard patch layout on Page 26
ST GRP OP (Stereo Group Outputs)
25 Way F D-type Patch Patch
Cct# Hot Cold Scrn St Grp OP 1-4 Ref** St Grp OP 5-8 Ref**
1 24 12 25 St Grp OP 1L
C33
St Grp OP 5L
C41
2 10 23 11 St Grp OP 1R
C34
St Grp OP 5R
C42
3 21 9 22 St Grp OP 2L
C35
St Grp OP 6L
C43
4 7 20 8 St Grp OP 2R
C36
St Grp OP 6R
C44
5 18 6 19 St Grp OP 3L
C37
St Grp OP 7L
C45
6 4 17 5 St Grp OP 3R
C38
St Grp OP 7R
C46
7 15 3 16 St Grp OP 4L
C39
St Grp OP 8L
C47
8 1 14 2 St Grp OP 4R
C40
St Grp OP 8R
C48
ST (Stereo) Return Inputs
25 Way F D-type Patch
Cct# Hot Cold Scrn St Rtn IP 1-4 Ref**
1 24 12 25 St Rtn IP 1L
H33
2 10 23 11 St Rtn IP 1R
H34
3 21 9 22 St Rtn IP 2L
H35
4 7 20 8 St Rtn IP 2R
H36
5 18 6 19 St Rtn IP 3L
H37
6 4 17 5 St Rtn IP 3R
H38
7 15 3 16 St Rtn IP 4L
H39
8 1 14 2 St Rtn IP 4R
H40
Monitor Outputs
25 Way F D-type Monitor Patch
Cct# Hot Cold Scrn Outputs Ref**
1 24 12 25 Main L
G41
2 10 23 11 Main R
G42
3 21 9 22 Alt Mon 1L
G43
4 7 20 8 Alt Mon 1R
G44
5 18 6 19 Alt Mon 2L
G45
6 4 17 5 Alt Mon 2R
G46
7 15 3 16 Alt Mon 3L
G47
8 1 14 2 Alt Mon 3R
G48
External Inputs (and TB/Lstn Mic Parallel IPs)
25 Way F D-type Patch
Cct# Hot Cold Scrn External IP 1-3 Ref**
1 24 12 25 External IP 1 L
J33
2 10 23 11 External IP 1 R
J34
3 21 9 22 External IP 2 L
J35
4 7 20 8 External IP 2 R
J36
5 18 6 19 External IP 3 L
J37
6 4 17 5 External IP 3 R
J38
7 15 3 16 Tb Mic In Parallel
J39
8 1 14 2 Listn Mic In ||lel
J40
Cue/Aux Outputs
25 Way F D-type Cue A,B Aux 1-4 Patch
Cct# Hot Cold Scrn Outputs Ref**
1 24 12 25 St Cue OP A L
I41
2 10 23 11 St Cue OP A R
I42
3 21 9 22 St Cue OP B L
I43
4 7 20 8 St Cue OP B R
I44
5 18 6 19 Aux Output 1
I45
6 4 17 5 Aux Output 2
I46
7 15 3 16 Aux Output 3
I47
8 1 14 2 Aux Output 4
I48
Main Mix (Bus) Outputs and (Mix Bus) Insert Send
25 Way F D-type Patch
Cct# Hot Cold Scrn Main OPs Ref**
1 24 12 25 Mix Ins Snd L
K33
2 10 23 11 Mix Ins Snd R
K34
3 21 9 22 Mix OP L
K35
4 7 20 8 Mix OP R
K36
5 18 6 19 N/C
K37
6 4 17 5 N/C
K38
7 15 3 16 N/C
K39
8 1 14 2 Ext TB Out
K40
F/B (Foldback, Studio) and Misc Outputs
25 Way F D-type Osc, Foldback Patch
Cct# Hot Cold Scrn & Studio LS Ref**
1 24 12 25 Oscillator Out
K41
2 10 23 11 Listen Mic Out
K42
3 21 9 22 Foldback Out AL
K43
4 7 20 8 Foldback Out AR
K44
5 18 6 19 Foldback Out BL
K45
6 4 17 5 Foldback Out BR
K46
7 15 3 16 Studio L
K47
8 1 14 2 Studio R
K48
