Solid State Logic ORIGIN Installation Guide

ORIGIN Installation Guide
Appendix A
29
Crosstalk
Signal applied to Line Input of a mono channel, and routed to specified output by shortest path. All controls set flat, out or at unity
gain as appropriate. Pan set to full left or right.
Measurement Conditions Value
Channel Muting 20Hz to 20kHz <-100dB
Maximum Fader Attenuation 20Hz to 20kHz <-89dB
Pan pot Isolation 20Hz to 20kHz <-55dB
Routing
Channel to Main Mix <-94dB from 20Hz to 20kHz
Routing
Channel to Track Buses Channel routed to all buses apart from one under test
Channel not routed
<-64dB from 20Hz to 20kHz
<-113dB from 20Hz to 20kHz
Mic Input -50dBu applied to Mic Input at maximum gain, measured at
Direct Output, Monitor path selected
<-95dB
Overall Console Noise
Measured at main Mix outputs, channels routed as required with pans / balance controls centred, using Line input with termination.
All controls set flat, out or at unity gain as appropriate, channel and master faders calibrated for 0dB.
Measurement Conditions Value
Line to Mix
(Pan to centre)
1 channel routed
16 channels routed
24 channels routed
32 channels routed
<-93dBu
<-85dBu
<-83dBu
<-79dBu
Environmental Requirements
Temperature range:
Operating: +1 to 30 °C (+34 to 86 °F).
Storage: -20 to 50 °C (-4 to 122 °F).
