Solid State Logic ORIGIN Installation Guide

ORIGIN Installation Guide
Making Connections
22
Channel Direct Outputs
25 Way F D-type Patch Patch Patch Patch
Cct# Hot Cold Scrn Direct Out 1-8 Ref** Direct Out 9-16 Ref** Direct Out 17-24 Ref** Direct Out 25-32 Ref**
1 24 12 25 Direct Out 1
K1
Direct Out 9
K9
Direct Out 17
K17
Direct Out 25
K25
2 10 23 11 Direct Out 2
K2
Direct Out 10
K10
Direct Out 18
K18
Direct Out 26
K26
3 21 9 22 Direct Out 3
K3
Direct Out 11
K11
Direct Out 19
K19
Direct Out 27
K27
4 7 20 8 Direct Out 4
K4
Direct Out 12
K12
Direct Out 20
K20
Direct Out 28
K28
5 18 6 19 Direct Out 5
K5
Direct Out 13
K13
Direct Out 21
K21
Direct Out 29
K29
6 4 17 5 Direct Out 6
K6
Direct Out 14
K14
Direct Out 22
K22
Direct Out 30
K30
7 15 3 16 Direct Out 7
K7
Direct Out 15
K15
Direct Out 23
K23
Direct Out 31
K31
8 1 14 2 Direct Out 8
K8
Direct Out 16
K16
Direct Out 24
K24
Direct Out 32
K32
Channel DB-25 Pinouts cont'd
**NOTE: Patch Reference on following tables only applies if using suggested standard patch layout on Page 26
SF (Small Fader) Insert Returns
25 Way F D-type Patch Patch Patch Patch
Cct# Hot Cold Scrn SF Ins Rtn 1-8 Ref** SF Ins Rtn 9-16 Ref** SF Ins Rtn 17-24 Ref** SF Ins Rtn 25-32 Ref**
1 24 12 25 SF Ins Rtn 1
J1
SF Ins Rtn 9
J9
SF Ins Rtn 17
J17
SF Ins Rtn 25
J25
2 10 23 11 SF Ins Rtn 2
J2
SF Ins Rtn 10
J10
SF Ins Rtn 18
J18
SF Ins Rtn 26
J26
3 21 9 22 SF Ins Rtn 3
J3
SF Ins Rtn 11
J11
SF Ins Rtn 19
J19
SF Ins Rtn 27
J27
4 7 20 8 SF Ins Rtn 4
J4
SF Ins Rtn 12
J12
SF Ins Rtn 20
J20
SF Ins Rtn 28
J28
5 18 6 19 SF Ins Rtn 5
J5
SF Ins Rtn 13
J13
SF Ins Rtn 21
J21
SF Ins Rtn 29
J29
6 4 17 5 SF Ins Rtn 6
J6
SF Ins Rtn 14
J14
SF Ins Rtn 22
J22
SF Ins Rtn 30
J30
7 15 3 16 SF Ins Rtn 7
J7
SF Ins Rtn 15
J15
SF Ins Rtn 23
J23
SF Ins Rtn 31
J31
8 1 14 2 SF Ins Rtn 8
J8
SF Ins Rtn 16
J16
SF Ins Rtn 24
J24
SF Ins Rtn 32
J32
