Solid State Logic SiX User Manual

SiX User Guide
Appendix A
26
Appendix A - Physical Specication
Front to Back Depth 310 mm / 12.2 inches
Height (from table top inc. feet) 120 mm / 4.7 inches
Width 218 mm / 8.6 inches (Excluding Trim)
270 mm / 10.6 inches (Including Trim)
Power 38 Watts
Unboxed Weight 3.5 kg / 7.7 lbs
Boxed Size Depth x Height x Width
325 mm x 155 mm x 360 mm (12.8" x 6.1" x 14.2")
Boxed Weight 6.0 kg / 13.3 lbs
Note: All physical specication values are approximate.
Connector Pinouts
Mono Channels
Microphone Inputs
3-pin XLR Male
Pin Description
1 0V Chassis
2 Signal +ve (Hot)
3 Signal -ve (Cold)
Stereo Channels
Stereo Channel Line Inputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0V Chassis
Talkback Microphone Input
3-pin XLR Female
Pin Description
1 0V Chassis
2 Signal +ve (Hot)
3 Signal -ve (Cold)
Line Inputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0V Chassis
External Inputs
Stereo External Line Inputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0V Chassis
Foldback/Stereo Cue Outputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0V Chassis

Solid State Logic SiX Specifications

General

Type	Analog Mixer
Channels	6
EQ	2-band Channel EQ
Compressor	Yes, on Mono Channels
Talkback	Yes
EQ Bands	2
Aux Sends	2
Bus Compressor	Yes, on Main Mix Bus
Phantom Power	48V
Headphone Output	2
Monitor Output	2
Main Output	2
USB Audio Interface	2x2 USB Interface
