Solid State Logic SiX User Manual

SiX User Guide
Appendix B
30
Overall Channel Signal Chain Specications
Signal applied to Line Input of a mono channel, and routed to specied output by shortest path. All controls set at, out or at unity
gain as appropriate. Pan set to full left or right.
Measurement Conditions Value
Foldback, B-Bus & Main Output
Output Headroom into 600Ω at onset of clipping
into 10kΩ at onset of clipping
>24dBu
>27.5dBu
THD+Noise +20dBu @ 1kHz (lter 22Hz to 22kHz) < 0.0015%
Frequency Response 20Hz to 20kHz
-3dB high rolloff
+0.1/-0.3dB
>100kHz
Output Impedance 100Ω
Pot centre detent accuracy: +/-1dB, typically <0.5dB
Overall Console Noise
Measured at main outputs, channels routed as required with pans / balance controls centred, using Line input with termination. All
controls set at, out or at unity gain as appropriate, channel and master faders calibrated for 0dB.
Measurement Conditions Value
Noise at Main Output 1 mono channel routed (all other muted)
All channels routed
<-90dBu
(<–116dB with respect to +26dBu)
< –85dBu
(<–111dB with respect to +26dBu)
Environmental Requirements
Temperature range:
Operating: +1 to 30 degrees Celsius.
Storage: -20 to 50 degrees Celsius.

Solid State Logic SiX Specifications

General

Type	Analog Mixer
Channels	6
EQ	2-band Channel EQ
Compressor	Yes, on Mono Channels
Talkback	Yes
EQ Bands	2
Aux Sends	2
Bus Compressor	Yes, on Main Mix Bus
Phantom Power	48V
Headphone Output	2
Monitor Output	2
Main Output	2
USB Audio Interface	2x2 USB Interface
