Solid State Logic SiX User Manual

SiX User Guide
Appendix B
29
Channel Equaliser
Signal applied to line input and measured at the channel insert send. EQ switched in with EQ controls centred in shelf mode.
Measurement Conditions Value
Output Headroom >+27dBu at onset of clipping
THD+Noise +20dBu @ 1kHz (lter 22Hz to 22kHz) < 0.0015%
Noise <-88dBu
Channel Compressor
Signal applied to line Input and measured at the channel insert send. Compressor switched into channel path with the compressor’s
threshold set to +10dB.
Measurement Conditions Value
Ratio (slope)
Threshold
Attack Time
Release Time
2:1
+10 to -20 dB (typical)
8ms to 30ms
300ms
Output Headroom >+26dBu at onset of clipping
THD+Noise +10dBu @ 1kHz (lter 22Hz to 22kHz)
+20dBu @ 1kHz (lter 22Hz to 22kHz) Threshold @-20
< 0.03%
< 0.5% (typical)
Frequency Response - 20Hz to 20kHz +0.9/-0.9dB
Noise <-90dBu
SuperAnalogue Stereo Channel Line Input Amplier
Signal applied to stereo channel line input and measured at main output insert send with the stereo channel’s input gain trim and
balance controls in their indent position with the stereo channel’s fader adjusted for unity gain.
Measurement Conditions Value
Gain Variable from -10dB to +20dB
Input Impedance 10kΩ
Max Input Level 1% THD >+31dBu before clipping
Output Headroom >+27dBu at onset of clipping
Frequency Response - 20Hz to 20kHz
- -3dB high rolloff
+0.1/-0.3dB
> 100kHz
THD+Noise (-20dBu applied, +30dB gain) @ 1kHz (lter 22Hz to 22kHz) < 0.0007%
CMRR > 50dB
Equivelant Input Noise (EIN) 150Ω termination, maximum gain <-93dBu

Solid State Logic SiX Specifications

General

Type	Analog Mixer
Channels	6
EQ	2-band Channel EQ
Compressor	Yes, on Mono Channels
Talkback	Yes
EQ Bands	2
Aux Sends	2
Bus Compressor	Yes, on Main Mix Bus
Phantom Power	48V
Headphone Output	2
Monitor Output	2
Main Output	2
USB Audio Interface	2x2 USB Interface
