Solid State Logic SiX User Manual

SiX User Guide
Introduction
1
Introduction
SiX is a studio grade, SuperAnalogue mixing console that delivers all of the quality and exibility audio professionals expect
from an SSL console, but in a compact package that is designed to be small enough to t into hand luggage. Its design doesn't
compromise on performance because of its size, but delivers a powerful set of professional features in a small 1/2 rack width
package.
Audio Excellence
➤ Two SuperAnalogue wide gain range mic pres for pristine recording quality
➤ Two wide gain range stereo line inputs
➤ Individually switchable phantom power on each Mic Input
➤ Line level input with true HiZ (1 MΩ) impedance switch for passive coil inputs (e.g. guitar pickups)
➤ Two recording channels with fully balanced inserts, simple SSL EQ and Dynamics and true bypass processing switching
➤ Fast, accurate peak response LED meters
Mixing Versatility
➤ 12 channel stereo summing - probably more studio grade analogue summing per square inch than any other console
➤ Main bus with fully balanced insert
➤ Simplied SSL Bus Compressor
➤ 100 mm studio grade long throw faders - unique in this form factor
Application Flexibility
➤ A ‘proper’ foldback section with two stereo send/cue buses with talkback, local monitoring plus two stereo cue feeds
➤ Versatile B-Bus/Mute switching provides record and mix buses for simple overdubs
➤ Useful, exible signal routing and summing
➤ Versatile ‘summing’ monitor section with two external source selectors
➤ ‘Listen mic compressor’ with exible routing for studio talkback or more creative applications

Solid State Logic SiX Specifications

General

Type	Analog Mixer
Channels	6
EQ	2-band Channel EQ
Compressor	Yes, on Mono Channels
Talkback	Yes
EQ Bands	2
Aux Sends	2
Bus Compressor	Yes, on Main Mix Bus
Phantom Power	48V
Headphone Output	2
Monitor Output	2
Main Output	2
USB Audio Interface	2x2 USB Interface
