Solid State Logic SiX User Manual

Contents
SiX User Guide
Troubleshooting & FAQs 24
Troubleshooting Tips 24
Warranty 25
All returns 25
Appendix A - Physical Specication 26
Connector Pinouts 26
Mono Channels 26
Stereo Channels 26
Insert Sends/Returns, Alternate Inputs and Auxilliary Outputs 27
DC Power Inlet 27
Appendix B - Performance Specication 28
Audio Performance 28
SuperAnalogue Channel Microphone Amplier 28
SuperAnalogue Channel Line Input Amplier 28
Channel Equaliser 29
Channel Compressor 29
SuperAnalogue Stereo Channel Line Input Amplier 29
Overall Channel Signal Chain Specications 30
Overall Console Noise 30
Environmental Requirements 30
Appendix C - SiX Block Diagram 31
Appendix D - Recall Sheet 32

Solid State Logic SiX Specifications

General

Type	Analog Mixer
Channels	6
EQ	2-band Channel EQ
Compressor	Yes, on Mono Channels
Talkback	Yes
EQ Bands	2
Aux Sends	2
Bus Compressor	Yes, on Main Mix Bus
Phantom Power	48V
Headphone Output	2
Monitor Output	2
Main Output	2
USB Audio Interface	2x2 USB Interface
