User Manual
6.7 Advanced Settings - Technicians Only
NOTE
To access to this area is for fully qualified and accredited technicians only.
Please follow 6.4 to enter password to access this menu.
Select Advanced Settings from the Main Menu to access the following options:
1. Select Standard
2. Grid ON/OFF
3. Clear Energy
4. Reset Password
5. Power Control
6. Calibrate Energy
7. Special Settings
8. STD. Mode Settings
9. Restore Settings
10. HMI Update
11. External EPM set
12. Restart HMI
13. Debug Parameter
14.DSP Update
15.Compensation Set
16.I/V Curve
This function is used to select the grid reference standard (see Figure 6.16).
YES=<ENT> NO=<ESC>
Standard:UL-480V-A
Figure 6.16
6.7.1 Selecting Standard
Selecting the āUser-Defā menu will access the following sub-menu (see Figure 6.17).
Figure 6.17
OV-G-V1: 260V
OV-G-V1-T: 1.0S
Below is the range for each setting for use in the User-Def function. You may change the limit
manually thus creating a custom grid profile by using this function.
ā
6. Normal operation
42
