6. Operation6. Operation
6.4 Advanced Info - Technicians Only
NOTE:
To access to this area is for fully qualified and accredited technicians only.
Enter menu “Advanced Info.” and “Advanced settings” (need password).
Select “Advanced Info.” from the Main Menu. The screen will require the password as below:
YES=<ENT> NO=<ESC>
Password:0000
Figure 6.5 Enter password
The default password is “0010".
Please press “down” to move the cursor, press “up” to select the number.
After enter the correct password the Main Menu will display a screen and be able to access
to the following information.
1. Alarm Message
2. Running message
3.Version
4. Daily Energy
5. Monthly Energy
6. Yearly Energy
7. Daily Records
8. Communication Data
9. Warning Message
10. Inspection
6.4.1 Alarm Message
The display shows the latest alarm messages. Screens can be scrolled manually by 100
pressing the UP/ DOWN keys. Press the ESC key to return to the previous menu.
Alarm001: OV-G-V
Time: 00-00 Data: 0000
Figure 6.6 Alarm Message
6.4.2 Running Message
This function is for maintaince person to get running message such as internal temperature,
Standard No.etc.
Screens can be scrolled manually by pressing the UP/DOWN keys.
6.4.4 Daily Energy
The function is for checking the energy generation for selected day.
Figure 6.8 Select date for daily energy
YES=<ENT> NO=<E SC>
Select: 2020-01-01
Press DOWN key to move the cursor to day, month and year, press UP key to change the digit.
Press Enter after the date is fixed.
2020-01-01: 051.3kWh
2020-01-01: 061.5kWh
Figure 6.9 Daily energy
Press UP/DOWN key to move one date from another.
6.4.3 Version
The screen shows the model version and the software version of the Inverter
Model: 08
Software Version: D20001
Figure 6.7 Model Version and Software Version
6.4.5 Monthly Energy
YES=<ENT> NO=<E SC>
Select: 2020-01
Figure 6.10 Select month for monthly energy
The function is for checking the energy generation for selected month.
Press DOWN key to move the cursor to day and month, press U P key to change the digit.
Press Enter after the date is fixed.
2020-02: 0510kWh
2020-01: 0610kWh
Figure 6.11 Month energy
Press UP/DOWN key to move one date from another.
.31..30.
