6. Operation6. Operation
Selecting the “User-Def” menu will access to the following submenu.
Figure 6.18
OV-G-V1: 260V
OV-G-V1-T: 1S
NOTE:
The " User-Def" function can be only used by the service engineer and
must be allowed by the local energy supplier.
Below is the setting range for “User-Def”.
Using this function, the limits can be changed manually.
NOTE:
For different countries, the grid standard needs to be set as different
according to local requirements. If there is any doubt, please consult
Solis service technicians for details.
This function is used to start up or stop the power generation of Solis Single Phase Inverter.
Grid ON
Grid OFF
Stop
Figure 6.19 Set Grid ON/OFF
Screens can be scrolled manually by pressing the UP/DOWN keys. Press the ENTER key
to save the setting. Press the ESC key to return to the previous menu.
6.5.2 Grid ON/OFF
Table 6.2 Setting ranges for User-Def (L-N)
OV-G-V1: 176---290V
OV-G-V1-T: 0.01---600S
OV-G-V2: 176---290V
OV-G-V2-T: 0.01---600S
UN-G-V1: 110---220V
UN-G-V1-T: 0.01---600S
UN-G-V2: 110---220V
UN-G-V2-T: 0.01---600S
Startup-T: 10-600S
OV-G-F1: 50.1-65Hz
OV-G-F1-T: 0.01---600S
OV-G-F2: 50.1-65Hz
OV-G-F2-T: 0.01---600S
UN-G-F1: 45-59.9Hz
UN-G-F1-T: 0.01---600S
UN-G-F2: 45-59.9Hz
UN-G-F2-T: 0.01---600S
Restore-T: 10-600S
6.5.3 24H Switch
This function controls the 24H hours consumption function enable or disable.
Enable
Disable
Figure 6.20 Set 24H ON/OFF
NOTE:
When this is enabled, the inverter LCD will still be alive at night with the
power LED light on.If the grid is in malfunction at night, the system can’t
recover even after the grid is back to normal but the consumption data will
still be recorded in the meter. Until the sunrise, the system will start to work
again while the meter data can be uploaded to the Solis monitoring system
to calibrate the load consumption data.
These two functions are applicable by maintenance personnel only, wrong
operation will prevent the inverter from working properly.
6.5.4 Clear Energy
Clear Energy can reset the history yield of inverter.
.35..34.
Press the UP/DOWN keys to select the standard (AS4777-02,AS4777-15, VDE4105,
VDE0126, UL-240V-A, UL-208V-A, UL-240V, UL-208V, MEX-CFE, G83/2 (for 1-3.6kW
models), G59/3 (for 4-5kW models), C10/11, EN50438 DK, EN50438 IE, EN50438 NL and
“User-Def” function).
NOTE:
This function is for technicians use only.
Grid ON, start up the power generation.
Grid OFF, stop the power generation, while the inverter is disconnected from the power grid.
Stop, stop the power generation, while the inverter is still connected with the power grid.
