UM0027_ SOL APOLLO Series 7.4-22K_EN_V02_0523 43
3. Remove the external nut (A), then remove the rubber plug (B). Next, insert
the ethernet cable into the hole (C). Repeat the similar step for the
RS-485 cable installation.
A
B
C
Figure 33
4. Assemble the cable gland and loosen the external nut (A).
A
Figure 34
5. Install the cable gland at the bottom of the enclosure and fasten the nut
(B), afterwards fasten the nut (A).
A
B
Figure 35
