Solplanet SOL APOLLO Series - Page 45

44 UM0027_ SOL APOLLO Series 7.4-22K_EN_V02_0523
6. Insert the RJ-45 plug of the ethernet cable in the RJ-45 socket (A). Connect
the RS-485 cable in the RS-485 socket (B).
A
B
Figure 36
Insert 4G SIM card (optional)
Insert the SIM card (A) into the sim card holder (B). Ensure the position of the
connection points are correct.
Figure 37
