CHAPTER 2
HARDWARE SETUP
2-1 CPU INSTALLATION
2-2 MEMORY INSTALLATION
2-3 AGP PRO INSTALLATION
2-4 HDD/FDD INSTALLATION
2-5 SWITCH SETTING FOR CPU RATIO AND CLOCK
2-6 JUMPER SETTING FOR DEVICES ON BOARD
2-7 CONNECTORS CONFIGURATION
2-8 IRQ DESCRIPTION
ATTENTION !!!
1. Please refer to your processor installation or other
documentation attached to your CPU for more detailed
installing instruction.
2. Installing a heat sink and cooling fan is necessary for
proper heat dissipation from your CPU. Incorrect in-
stallation may result in overheating and damage of
your CPU.
3. Before changing the setting of CPU Vcore from BIOS
program, user SHOULD make sure of correct specifi-
cation both of CPU CLOCK and RATIO. Incorrect set-
ting may cause damage to your CPU.
This chapter contains the following topics :
