SOLTEK SL-65KIV - 2-7.3 CD-ROM Audio Connector (CD_IN1;CD_IN2)

31
Hardware Setup
2-7.3 CD-ROM Audio Connector (CD_IN1/CD_IN2)
CD-ROM Audio Connector:
PIN NO.
PIN 1
GND
PIN 2
GND
PIN 3
Right
Channel
PIN 4
Left
Channel
Left
Channel
GND
Right
Channel
GND
CD_IN1 CD_IN2
