Hardware Setup
2-3 ACCELERATED GRAPHICS PORT(AGP) PRO INSTALLATION
• The AGP Pro connector is an extension of the existing AGP connector and
it is compatible with existing AGP cards.
CAUTION!!
The AGP Pro slot comes with a warning label over the 20-pin bay. Do not
remove this label and the safety tab underneath if you use an AGP card
without a retention notch. Without the labels, AGP cards may be placed
into the wrong place, which certainly will damage your card, slot, and
mainboard. Remove the label ONLY if you will be using an AGP Pro card.
AGP Accelerator
AGP
To Next Page
