The fitting punch can be operated by means of a 5/2 hand-driven and / or a 5/2 foot-driven control
valve without additional safety devices.
A filter regulator is necessary to protect the cropping cylinder from dirt. Attention must be paid to
regular discharge of condensed water and dirt collection on the filter!
When accessories have been supplied please connect the cropper as follows:
- Connect the output at the filter regulator with interface 1 of the foot valve
- Connect output 2 of the foot valve with the cropper back stroke
- Connect output 4 of the foot valve with the cropper front stroke
- Connect input of the filter regulator 1/4“ with compressed air supply
- Use the pneumatic pipe supplied to connect
- For connections of the cropper refer to page 14
9 Operation & tool replacement & Maintenance
9.1 Operation
Please make sure that the device is in proper working
condition and that nobody can stand in the hazardous
area.
• Please ensure that the fitting cropper is fixed scurely on a table at a suitable height, but,
however, not beyond one meter.
• Please note while fixing the cropper that the residue of the cropped material can fall down
without obstruction. (Blockage of the residue can lead to breakage of the tool)
