5
GETTING STARTED
WHAT IS IN THE BOX?
The list of items in the Sonim XP3plus phone box are:
• Sonim XP3plus
• Battery
• SIM Card
• Wall Charger
• USB-C Cable
• Screwdriver
• Battery Cover
• Quick Start Guide
PHONE SPECIFICATIONS
FEATURE DESCRIPTION
Chipset Qualcomm SM6115
Band
North America Roaming
• GSM:
850MHz,
1900MHz
• UMTS: II,
IV, V
• LTE: B2, B4,
B5, B7, B12,
B13, B14,
B25, B26,
B30, B41,
B66, B71
(B41 HPUE
Power Class
2)
• GSM: 900MHz,
1800MHz
• UMTS: I
• LTE: B1, B3, B39,
B40
Down link CA CA_2A-2A, CA_2A-4A, CA_2A-5A,
CA_2A-12A, CA_2A-13A, CA_2A-14A,
CA_2A-66A, CA_2A-71A, CA_2C,
CA_4A-4A, CA_4A-5A, CA_4A-12A,
CA_4A-13A, CA_4A-71A, CA_5A-5A,
CA_5A-41A, CA_5A-66A, CA_5B,
CA_12A-66A, CA_13A-66A, CA_14A-
66A, CA_25A-25A, CA_25A-26A,
CA_26A-41A, CA_41A-41A, CA_41C,
CA_66A-66A, CA_66A-71A, CA_66B,
CA_66C
FEATURE DESCRIPTION
Wi-Fi Dual band, 802.11 a/b/g/n/ac with
hotspot function excluding Wi-Fi 5G
band 2/3
Memory 16GB Bytes eMMC + 2GB Bytes
LPDDR, Micro SD
Languages
Supported
English, Spanish*, Canadian French*,
Korean* and Simplied Chinese*
Battery Removable Li-ion battery, 3.85V,
2300mAh
CONNECTIVITY
Bluetooth BT5.0/BLE (Low Energy)
SMS/MMS Support SMS and MMS
GPS GPS/aGPS, GLONASS
PHYSICAL CHARACTERISTICS
Ambient
Temperature
-20ºC to +55ºC (-4°F to 131°F)
Protection
Class
IP68
Size 116mm x 60mm x 28mm
Weight 223g
Dedicated
Keys
PTT Key, Emergency Key, Dynamic/
Programmable Keys
Ports USB Type C port, SecureAudio 3.5mm
Connector
DISPLAY
SIZE Internal/External: 2.8" / 1.3"
Resolution Internal/External: 240x320 / 240x240
Outdoor
Visibility
Yes
Capacity 262K
AUDIO
Microphone 2 Mics with noise cancellation
Speaker
Front Speaker with smart PA, Support
HD voice and wide band
1
* Language availability based on region.
