Sonim XP3plus User Manual

6
FEATURE DESCRIPTION
MULTIMEDIA
Audio Formats
AMR-NB, AMR-WB, AAC, AAC+,
AAC+V2, MP3, V-SELP, AMR 12.65,
AMR 6.6
Video Formats
3GP, MP4, AVI, MOV, MPEG-4, H.263,
H.264, H-265
FM Radio Yes
Camera
Camera Version 8MP FF Rear camera, Front camera
Non-camera
Version
No Rear camera, No Front camera
All camera features are not applicable for the non-
camera variant devices.
LED Torch light Yes, also used for camera ash.
If Flash notication alert is enabled, when
battery is above 20% level, you can use camera
ashlight for missed events.
SIM CARD
The SIM (Subscriber Identity Module) card associates
your network services (for example, phone number, data
services etc.) with your phone.
The Sonim XP3plus device comes with single SIM card and
Memory card trays.
INSERTING THE SIM CARD
1. UNSCREW COVER
Use the included
screwdriver to
unscrew the
battery cover
screw on the
back of the
phone.
2. LIFT THE COVER
Lift the back
cover to reveal
the battery slot.
3. REMOVE THE
BATTERY
After removing
the back cover
lift the battery
from the battery
compartment.
4. Open SIM card
tray, insert SIM
card and lock
SIM card tray into
the place.
PLEASE ENSURE THAT A VALID NANO SIM
CARD IS INSERTED IN YOUR PHONE.
GETTING STARTED

Sonim XP3plus Specifications

General

Display Size	2.8 inches
Resolution	240 x 320 pixels
Battery Capacity	2300 mAh
Rear Camera	5 MP
Status	Available
Network	GSM / HSPA / LTE
2G bands	GSM 850 / 900 / 1800 / 1900
3G bands	HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
Speed	HSPA, LTE
MIL-STD-810H compliant	Yes
Type	TFT
CPU	Quad-core 1.3 GHz Cortex-A53
Loudspeaker	Yes
3.5mm jack	Yes
Bluetooth	4.2, A2DP
GPS	Yes, with A-GPS, GLONASS
NFC	Yes
Radio	FM radio
USB	USB Type-C 2.0
Sensors	Accelerometer, proximity
Colors	Black
SIM	Dual SIM
IP rating	IP68 dust/water resistant (up to 1.5m for 30 min)
WLAN	Wi-Fi 802.11 a/b/g/n/ac
4G bands	1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 20, 25, 26, 28, 38, 39, 40, 41
