AVD-K150B/K150E/K150G/K150N/K150R
SECTION 7
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• CAPACITORS
uF: µF
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
•Abbreviation
AED : North European model
RU : Russian model
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
9-885-055-48 DISPLAY BOARD,COMPLETE
***********************
< INDICATOR TUBE >
DG601 9-885-055-97 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 8-759-643-83 IC UPD16315GB-3BS
< DIODE >
LED602 9-885-055-98 DIODE, LED DL-11S2GNS (DVD)
LED603 9-885-055-98 DIODE, LED DL-11S2GNS (VIDEO)
< CONNECTOR >
P6V01 9-885-056-99 CONNECTOR,BOARD TO BOARD 12PIN
P6V02 9-885-056-00 CONNECTOR,BOARD TO BOARD 7PIN
PS602 1-816-678-11 CONNECTOR,BOARD TO BOARD 8PIN
< IC >
RC601 1-478-247-11 REMOTE CONTROLLER RECEIVER (
)
< SWITCH >
SW601 1-572-184-21 SWITCH,TACT (A VIDEO)
SW602 1-572-184-21 SWITCH,TACT (X)
SW603 1-572-184-21 SWITCH,TACT (x)
SW604 1-572-184-21 SWITCH,TACT (ML)
SW605 1-572-184-21 SWITCH,TACT (H)
SW606 1-572-184-21 SWITCH,TACT (lm)
SW607 1-572-184-21 SWITCH,TACT (REC)
SW608 1-572-184-21 SWITCH,TACT (DVD/VIDEO)
SW609 1-572-184-21 SWITCH,TACT (A DVD)
< ENCODER >
VR601 9-885-055-02 ENCODER,VOLUME (VOLUME)
************************************************************
9-885-062-68 DVD & AMP BOARD,COMPLETE (150B)
9-885-062-74 DVD & AMP BOARD,COMPLETE (150E)
9-885-062-82 DVD & AMP BOARD,COMPLETE (150G)
9-885-062-86 DVD & AMP BOARD,COMPLETE (150N)
9-885-062-91 DVD & AMP BOARD,COMPLETE (150R)
********************************
< DIODE >
D501 6-500-323-01 DIODE RL104 R
D603 8-719-991-34 DIODE 1SS133
D604 8-719-991-34 DIODE 1SS133
<IC >
IC101 9-885-055-65 IC LC875747B-52A5
IC102 9-885-032-96 IC KIA7031P
IC103 9-885-032-96 IC KIA7031P
IC104 8-759-745-64 IC NJM4560M-TE1
IC202 9-885-055-66 IC AK4586VQ
IC203 8-759-297-77 IC MM1231XFBE
IC204 8-759-656-83 IC NJM4580M
IC205 8-759-745-64 IC NJM4560M-TE1
IC206 9-885-055-67 IC CS4334-KS
IC301 9-885-054-83 IC PS9702B
IC401 9-885-041-57 IC MT1336E
IC402 6-705-366-01 IC LA6560-A-TE
IC501 9-885-055-68 IC MT1379DEC
IC502 6-700-173-01 IC HY57V161610DTC-7
IC503 6-700-173-01 IC HY57V161610DTC-7
IC505 6-702-399-01 IC S524A40X21-SCT0
IC507 9-885-041-64 IC MM1623XFBE
IC5A1 9-885-062-95 IC PROGRAM, DTS60913S DVD (150B/150E)
IC5A1 9-885-062-96 IC PROGRAM, DTS60913I DVD (150G)
IC5A1 9-885-062-97 IC PROGRAM, DTS60913Y DVD (150N)
IC5A1 9-885-062-99 IC PROGRAM, DTS60911X DVD (150R)
IC710 9-885-054-79 IC STA505
IC730 9-885-054-79 IC STA505
IC750 9-885-054-79 IC STA505
IC770 9-885-054-79 IC STA505
< JACK/TERMINAL >
JK602 8-749-923-05 JACK, TORX178 (VIDEO 1)
JKS01 1-694-998-11 TERMINAL BLOCK, 6P (SPEAKERS)
< CONNECTOR >
PDV01 9-885-055-74 CONNECTOR,MA 12PIN WH
PDV02 9-885-054-96 CONNECTOR,12PIN 1.25mm
PDV03 9-885-054-96 CONNECTOR,12PIN 1.25mm
PDM03 9-885-055-75 CONNECTOR,11P 1.0mm
PDM01 9-885-055-76 CONNECTOR,23P 1.0mm
DISPLAY DVD & AMP
