51 (E)
Chapter 3 Appendix
.............................................................................................................................................................................................................................................
2)The aperture cannot be compensated for RGB input signals.
Video signal
Frequency response
575/50I, 480/60I component inputs
BVM-D9H1U/D9H1E/D9H1A/
D9H5U/D9H5E/D9H5A/
D14H1U/D14H1E/D14H1A/
D14H5U/D14H5E/D14H5A:
50Hz to 10MHz (0 dB/–3 dB)
Models other than the above or
RGB inputs
BVM-D9H1U/D9H1E/D9H1A/
D9H5U/D9H5E/D9H5A:
48 Hz to 17 MHz, (1 dB/ –3 dB)
BVM-D14H1U/D14H1E/
D14H1A/D14H5U/D14H5E/
D14H5A:
48 Hz to 24 MHz, (0 dB/ –3 dB)
Aperture compensation
2)
OFF: 0 dB
ON: 2 dB to 6 dB
575/50I, 480/60I inputs: 5 MHz
Input other than the above: 16 MHz
Picture performance
Normal scan 5% overscan of CRT effective
screen area (adjustable range
greater than ±15%)
Underscan 3% underscan of CRT effective
screen area (adjustable range
greater than ±15%)
Linearity Within a central area bounded by a
circle with a diameter equal to the
picture height, less than 1.0 % of
the picture height, and outside the
same area, about 2.0 % of the
picture height
Color temperature
D93, D65 (adjustable to other color
temperatures)
Convergence error
Within a central area bounded by a
circle with a diameter equal to the
picture height.
Less than 0.4 mm with a central
area bounded by a circle and less
than 0.7 mm at any other point.
Standard luminescence
120 cd/m
2
(at standard 1 Vp-p
100% white signal)
Raster size stability
Less than 1% of picture height (at
120 cd/m
2
peak luminescence, 10
to 90% APL)
Resolution (at screen center, 120 cd/m
2
luminescence)
BVM-D9H1U/D9H1E/D9H1A/
D9H5U/D9H5E/D9H5A:
340 TV lines (16:9)
450 TV lines (4:3)
BVM-D14H1U/D14H1E/D14H1A/
D14H5U/D14H5E/D14H5A:
600 TV lines (16:9)
800 TV lines (4:3)
Operating conditions
Temperature 0°C to 35°C (32°F to 95°F)
Optimum temperature
20°C to 30°C (68°F to 86°F)
Humidity 0% to 90% (no condensation)
Pressure 700 hPa to 1060 hPa
Storage and transport conditions
Temperature –10°C to 40°C (14°F to 104°F)
Humidity 0% to 90%
Pressure 700 hPa to 1060 hPa
