50 (E)
Chapter 3 Appendix
Specifications
Power requirements
BVM-D9H1U/D9H1E/D9H1A/
D9H5U/D9H5E/D9H5A:
AC 100 to 240 V, 50/60 Hz, DC
12V
+5
V
-1
BVM-D14H1U/D14H1E/D14H1A/
D14H5U/D14H5E/D14H5A:
AC 100 to 240 V, 50/60 Hz
Input/output connectors
Video input/outputBNC type × 3 (with loop-through
outputs, 75-ohm automatic
termination)
R/G/B: 1 Vp-p ±6 dB, positive,
high impedance
Y: 1 Vp-p ±6 dB, high impedance
P
B/PR: 0.7 Vp-p ±6 dB, high
impedance
Sync input/output BNC type × 1 (with loop-through
output, 75-ohm automatic
termination)
Composite sync: 0.3 to 8 Vp-p,
positive/negative tri-level sync
signal input or negative bi-level
sync signal input, high impedance
Return loss More than 40 dB (10 MHz, with
75-ohm termination)
Remote control OPTION: Mini-DIN 8-pin × 1
CONTROL UNIT:
D-sub 9-pin × 1 (BVM-D9H1U/
D9H1E/D9H1A
1)
, BVM-
D14H1U/D14H1E/D14H1A
only)
PARALLEL REMOTE
1:
D-sub 9-pin × 1
PARALLEL REMOTE
2:
Modular connector 6-pin
SERIAL REMOTE: D-sub 9-pin ×
2
1)
(with loop-through output)
Audio input (BVM-D9H5U/D9H5E/D9H5A only)
Phono jack × 3 (with loop-through
output)
................................................................................................................................................................................................................................................
1)BVM-D9H1U/D9H1E/D9H1A is swithced to REMOTE
or CTRL UNIT with the select switch.
Mass BVM-D9H1U/D9H1E/D9H1A:
approx. 8.1 kg (17 lb 14 oz)
when the AC adaptor is installed:
approx. 8.9 kg (19 lb 10 oz)
BVM-D9H5U/D9H5E/D9H5A:
approx. 9.3 kg (20 lb 8 oz)
when the AC adaptor is installed:
approx. 10.1 kg (22 lb 4 oz)
BVM-D14H1U/D14H1E/D14H1A:
approx. 21 kg (46 lb 5 oz)
BVM-D14H5U/D14H5E/D14H5A:
approx. 23 kg (50 lb 11 oz)
Power consumption
BVM-D9H1U/D9H1E/D9H1A/
D9H5U/D9H5E/D9H5A:
85 W max. (an optional BKM-
142HD or BKM-120D is
installed)
60 W typical (the supplied analog
component input adaptor is
installed)
BVM-D14H1U/D14H1E/D14H1A/
D14H5U/D14H5E/D14H5A:
115 W max. (an optional BKM-
142HD or BKM-120D is
installed)
100 W typical (the supplied
analog component input adaptor
is installed)
Peak inrush current
(1) Power ON, current probe
method: 80 A (240 V) (BVM-
D9H1U/D9H1E/D9H1A/
D9H5U/D9H5E/D9H5A),
45 A (240 V) (BVM-D14H1U/
D14H1E/D14H1A/D14H5U/
D14H5E/D14H5A)
(2) Hot switching inrush current,
measured in accordance with
European standard
EN55103-1: 14.7 A (230 V)
(BVM-D9H1U/D9H1E/D9H1A/
D9H5U/D9H5E/D9H5A),
21.2 A (230 V) (BVM-D14H1U/
D14H1E/D14H1A/D14H5U/
D14H5E/D14H5A)
