25
XR-CA430X/CA440
Pin No. Pin Name I/O Description
91 TAPEON O
Power on/off control signal output of the loading motor drive (IC351) and capstan/reel motor
(M901) “H”: motor on
92 CMON O
Capstan/reel motor (M901) drive signal output terminal “H”: motor on
93 NOSESW I
Front panel block remove/attach detection signal input
“L”: front panel is attached, “H”: front panel is removed
94 NS_MASK O
Discharge control signal output for the noise detection circuit “H”: discharge
95 DAVSS —
Ground terminal (for D/A converter)
96 to 99
NCO O Not used (open)
100 DAVCC —
Power supply terminal (+5V) (for D/A converter)
*1 Loading motor control
STOP
LOADING/
FORWARD
EJECT/
REVERSE
BRAKE
LMLOD (pin il )
“L”“H”“L”“H”
LMEJ (pin o; )
“L”“L”“H”“H”
Terminal
Mode
