XR-CA430X/CA440
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
KEY
KEY BOARD
**********
1-694-883-11 CONDUCTIVE BOARD, CONNECTION
3-236-595-01 PLATE (LCD), LIGHT GUIDE
3-236-596-01 PLATE (LCD), GROUND
3-236-598-01 ILLUMINATOR (LCD) (CA430X)
3-236-598-11 SHEET (ILLUMINATOR) (CA440)
3-236-599-01 SHEET (REFLECTOR)
< CAPACITOR >
C991 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C992 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C993 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C994 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C995 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
< CONNECTOR >
CN901 1-794-312-11 PIN, CONNECTOR 12P
< DIODE >
D901 8-719-085-72 DIODE UMZ6.8ENTR
D991 8-719-056-79 DIODE UDZ-TE-17-4.7B (CA440)
D991 8-719-976-99 DIODE UDZ-TE-17-5.1B (CA430X)
< IC >
IC901 8-759-365-90 IC LC75824W
< LIQUID CRYSTAL DISPLAY >
LCD901 1-804-622-11 DISPLAY PANEL, LIQUID CRYSTAL (CA430X)
LCD901 1-804-628-11 DISPLAY PANEL, LIQUID CRYSTAL (CA440)
< LED >
LED902 8-719-038-07 LED CL-190PG-CD-T (SOURCE) (CA440)
LED902 8-719-061-16 LED CL-190SR-CD-T (SOURCE) (CA430X)
LED903 8-719-038-07 LED CL-190PG-CD-T (SOURCE) (CA440)
LED903 8-719-061-16 LED CL-190SR-CD-T (SOURCE) (CA430X)
LED906 8-719-038-05 LED CL-190FG-CD-T (MODE o) (CA440)
LED906 8-719-061-16 LED CL-190SR-CD-T (MODE o) (CA430X)
LED922 8-719-038-07 LED CL-190PG-CD-T (D-BASS) (CA440)
LED922 8-719-061-16 LED CL-190SR-CD-T (D-BASS) (CA430X)
LED923 8-719-038-07 LED CL-190PG-CD-T (D-BASS) (CA440)
LED923 8-719-061-16 LED CL-190SR-CD-T (D-BASS) (CA430X)
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
When indicating parts by reference
number, please include the board.
LED940 8-719-038-05 LED CL-190FG-CD-T (ILLUMINATION)
(CA440)
LED940 8-719-061-16 LED CL-190SR-CD-T (ILLUMINATION)
(CA430X)
LED950 8-719-038-05 LED CL-190FG-CD-T (ILLUMINATION)
(CA440)
LED950 8-719-061-16 LED CL-190SR-CD-T (ILLUMINATION)
(CA430X)
< SWITCH >
LSW900 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (Z)
(CA430X)
LSW900 1-786-124-11 SWITCH, KEY BOARD (WITH LED) (Z)
(CA440)
LSW901 1-771-883-11 SWITCH, TACTILE (WITH LED) (OFF) (CA430X)
LSW901 1-786-113-11 SWITCH, TACT (WITH LED) (OFF) (CA440)
LSW903 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (VOL +)
(CA430X)
LSW903 1-786-124-11 SWITCH, KEY BOARD (WITH LED) (VOL +)
(CA440)
LSW904 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (ATT)
(CA430X)
LSW904 1-786-124-11 SWITCH, KEY BOARD (WITH LED) (ATT)
(CA440)
LSW905 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (VOL –)
(CA430X)
LSW905 1-786-124-11 SWITCH, KEY BOARD (WITH LED) (VOL –)
(CA440)
LSW907 1-771-883-11 SWITCH, TACTILE (WITH LED)
(ALBM +, ATA, 6) (CA430X)
LSW907 1-786-113-11 SWITCH, TACT (WITH LED) (ALBM +, ATA, 6)
(CA440)
LSW908 1-771-883-11 SWITCH, TACTILE (WITH LED) (AE) (CA430X)
LSW908 1-786-113-11 SWITCH, TACT (WITH LED) (AE) (CA440)
LSW909 1-771-883-11 SWITCH, TACTILE (WITH LED) (BTM, SENS)
(CA430X)
LSW909 1-786-113-11 SWITCH, TACT (WITH LED) (BTM, SENS)
(CA440)
LSW910 1-771-883-11 SWITCH, TACTILE (WITH LED) (DISC –, 1)
(CA430X)
LSW910 1-786-113-11 SWITCH, TACT (WITH LED) (DISC –, 1)
(CA440)
LSW911 1-771-883-11 SWITCH, TACTILE (WITH LED) (DISC +, 2)
(CA430X)
LSW911 1-786-113-11 SWITCH, TACT (WITH LED) (DISC +, 2)
(CA440)
