Sony CDP-XE270 - CD Mechanism Deck (CDM66-5 BD27); MAIN Board

7
CDP-XE270/XE370
3-3. CD MECHANISM DECK (CDM66-5BD27)
3-4. MAIN BOARD
1 tapering driver
2
3
panel, loading
4 wire (flat type) (21core)
7 connector (CN151)
8 CD mechanism deck
(CDM66-5BD27)
– BOTTOM VIEW –
5 three screws
(BVTP3
× 8)
6
Note: When the power supply does not turn on,
rotate the cam with tepering driver (
∅ 3 mm) as the figure shows,
and the loading panel will be moved.
1 connector (CN602)
2 wire (flat type) (17core)
(CN621)
2 wire (flat type) (21core)
(CN651)
5 main board
3 four screws
(BVTP3 × 8
)
4 two screws
(BVTP3 × 8)
