Sony CDX-1150 - Roller Arm Assy; Optical Pick-Up Block

– 10 –
2-9. ROLLER ARM ASSY
2-10. OPTICAL PICK-UP BLOCK
1 spring (roller)
2 spring (roller)
7 roller arm assy
3
4
5
6
1 gear (worm wheel)
2 shaft (sled guide)
3 optical pick-up block
claw
