Sony CDX-1150 - Key Board; Main Sub Assy

– 7 –
2-3. KEY BOARD
2-4. MAIN SUB ASSY
2 P 2x8
1 P 2x8
4 button (6 key)
8 button (AMS)
7 button (EJECT)
6 button (+ -)
5 button (source)
3 KEY board
1 PTT 2.6x8
4 spacer (washer)
6 PTT 2.6x8
7 PTT 2.6x8
8 ground point screw
(+PTT 2.6x6)
9 ground point screws
(+PTT 2.6x6)
3 PTT 2.6x8
5 bracket (front)
0 main sub assy
!¡ sheet (insulating)
2 spacer (washer)
