SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark.
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
KEY
* A-3294-624-A KEY BOARD, COMPLETE
********************
* X-3377-104-1 HOLDER (LCD) ASSY
* 3-034-440-01 PLATE (LCD), GROUND
* 3-034-453-01 SHEET (DIFFUSION)
* 3-034-454-01 SHEET (LCD)
< CAPACITOR >
C851 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C853 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C854 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
< CONNECTOR >
CN800 1-764-423-11 PIN, CONNECTOR 12P
< DIODE >
D851 8-719-047-94 DIODE HZU5.1B2TLF
< IC >
IC800 8-759-330-60 IC LC75822WD
< LIQUID CRYSTAL DISPLAY >
LCD800 1-803-526-11 DISPLAY PANEL, LIQUID CRYSTAL
< SWITCH >
LSW800 1-771-206-11 SWITCH, KEY BOARD (RESET)
LSW801 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (OFF)
LSW802 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (SOURCE)
LSW803 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (MODE)
LSW804 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (SOUND)
LSW805 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (+)
LSW806 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (–)
LSW807 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (SEEK/AMS
) + +)
LSW808 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (SEEK/AMS
0 = –)
LSW809 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (SENS/BTM)
LSW810 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (LOUD)
LSW811 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (6)
LSW812 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (ATT)
LSW813 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (DSPL)
LSW814 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (1/REPEAT)
LSW815 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (2/SHUF)
LSW816 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (3)
LSW817 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (4)
LSW818 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (5)
LSW819 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (6)
< PILOT LAMP >
PL801 1-517-898-21 LAMP, PILOT
PL802 1-517-898-21 LAMP, PILOT
< RESISTOR >
R801 1-216-821-11 METAL CHIP 1K 5% 1/16W
R802 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R803 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R804 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R805 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R806 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R807 1-216-835-11 METAL CHIP 15K 5% 1/16W
R808 1-216-839-11 METAL CHIP 33K 5% 1/16W
R809 1-220-743-51 METAL CHIP 100K 0.50% 1/16W
R811 1-216-821-11 METAL CHIP 1K 5% 1/16W
R812 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R813 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R814 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R815 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R816 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R817 1-216-835-11 METAL CHIP 15K 5% 1/16W
R818 1-216-839-11 METAL CHIP 33K 5% 1/16W
R830 1-216-025-00 RES,CHIP 100 5% 1/10W
R831 1-216-025-00 RES,CHIP 100 5% 1/10W
R832 1-216-025-00 RES,CHIP 100 5% 1/10W
R833 1-216-025-00 RES,CHIP 100 5% 1/10W
R834 1-216-025-00 RES,CHIP 100 5% 1/10W
R835 1-216-033-00 METAL CHIP 220 5% 1/10W
R851 1-216-045-00 METAL CHIP 680 5% 1/10W
R852 1-220-737-51 METAL CHIP 1K 0.50% 1/16W
R853 1-218-733-11 METAL CHIP 51K 0.50% 1/16W
*************************************************************
* A-3294-623-A MAIN BOARD, COMPLETE
*********************
* 3-034-438-01 BRACKET (IC)
* 3-034-441-01 HEAT SINK
7-685-793-09 SCREW +PTT 2.6X8 (S)
MAIN
