Sony CDX-1150 - Chassis (R) Block Assy; Floating Block Assy

– 9 –
2-7. CHASSIS (R) BLOCK ASSY
2-8. FLOATING BLOCK ASSY
3 tension spring (FL)
1 screws (P 2x2.5)
2 chassis (R) block assy
4 tension spring (FL)
6
7
8
9
0
floating block assy
4 tension spring (SPM)
5 tension spring (angle)
2 washer (M)
3 lever (LE.L)
1 tension spring (lever D)
