Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 62 —
* 1-667-641-11 REC BOARD
**********
< SWITCH >
S301 1-762-565-11 SWITCH, SLIDE (REC)
************************************************************
* 1-668-684-11 RESET BOARD (US, CND)
************
< CONNECTOR >
CN320 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P (US, CND)
< SWITCH >
SW822 1-554-088-00 SWITCH, KEY BOARD (RESET) (US, CND)
************************************************************
* 1-667-646-11 SW1 BOARD
**********
1-782-831-11 WIRE, PARALLEL (30 CORE)
3-017-928-01 HOLDER, LCD
< CONNECTOR >
CN310 1-563-633-11 HOUSING, CONNECTOR 30P
< LIQUID CRYSTAL DISPLAY >
LCD801 1-801-875-11 DISPLAY PANEL, LIQUID CRYSTAL
< RESISTOR >
R802 1-249-415-11 CARBON 680 5% 1/4W F
R803 1-249-416-11 CARBON 820 5% 1/4W F
R804 1-249-418-11 CARBON 1.2K 5% 1/4W F
R805 1-249-420-11 CARBON 1.8K 5% 1/4W F
R806 1-247-843-11 CARBON 3.3K 5% 1/4W
R807 1-249-427-11 CARBON 6.8K 5% 1/4W F
R808 1-249-432-11 CARBON 18K 5% 1/4W
R809 1-249-415-11 CARBON 680 5% 1/4W F
R810 1-249-416-11 CARBON 820 5% 1/4W F
R811 1-249-418-11 CARBON 1.2K 5% 1/4W F
R812 1-249-420-11 CARBON 1.8K 5% 1/4W F
R813 1-247-843-11 CARBON 3.3K 5% 1/4W
R814 1-249-427-11 CARBON 6.8K 5% 1/4W F
R815 1-249-432-11 CARBON 18K 5% 1/4W
< SWITCH >
SW802 1-692-014-11 SWITCH, KEY BOARD (CLOCK)
SW803 1-692-014-11 SWITCH, KEY BOARD (TIMER)
SW804 1-692-014-11 SWITCH, KEY BOARD (STAND BY)
SW805 1-692-014-11 SWITCH, KEY BOARD (RADIO)
SW806 1-692-014-11 SWITCH, KEY BOARD (SLEEP)
SW807 1-692-014-11 SWITCH, KEY BOARD (FUNCTION)
SW809 1-692-014-11 SWITCH, KEY BOARD (CD+)
SW810 1-692-014-11 SWITCH, KEY BOARD (CD–)
SW811 1-692-014-11 SWITCH, KEY BOARD (PRESET)
SW812 1-692-014-11 SWITCH, KEY BOARD (PRESET)
SW813 1-692-014-11 SWITCH, KEY BOARD
(DISPALY/ENTER, MEMOLY)
SW814 1-692-014-11 SWITCH, KEY BOARD (TUNING/TIME SET–)
SW815 1-692-014-11 SWITCH, KEY BOARD (TUNING/TIME SET+)
SW816 1-692-014-11 SWITCH, KEY BOARD (MODE MONO/SET)
************************************************************
1-667-645-11 SW2 BOARD
**********
< DIODE >
D801 8-719-938-69 DIODE GL3PR8
D802 8-719-938-69 DIODE GL3PR8
< RESISTOR >
R817 1-249-415-11 CARBON 680 5% 1/4W F
R818 1-249-416-11 CARBON 820 5% 1/4W F
R819 1-249-418-11 CARBON 1.2K 5% 1/4W F
R820 1-249-420-11 CARBON 1.8K 5% 1/4W F
R822 1-249-407-11 CARBON 150 5% 1/4W F
R823 1-249-407-11 CARBON 150 5% 1/4W F
< SWITCH >
SW817 1-692-014-11 SWITCH, KEY BOARD (VOLUME–)
SW818 1-692-014-11 SWITCH, KEY BOARD (VOLUME+)
SW819 1-692-014-11 SWITCH, KEY BOARD (MEGABASS)
SW820 1-692-014-11 SWITCH, KEY BOARD (SOUND)
SW821 1-692-014-11 SWITCH, KEY BOARD (ESP)
************************************************************
* A-3306-941-A TUNER BOARD (US, CND)
************
* A-3306-948-A TUNER BOARD (AEP)
************
< CAPACITOR >
C2 1-162-294-31 CERAMIC 0.001uF 10% 50V
C3 1-162-306-11 CERAMIC 0.01uF 20% 16V
C4 1-102-960-00 CERAMIC 24PF 5% 50V
C5 1-162-203-31 CERAMIC 15PF 5% 50V
C7 1-161-055-00 CERAMIC 0.022uF 10% 50V
C8 1-162-201-31 CERAMIC 12PF 5% 50V
C9 1-102-821-00 CERAMIC 360PF 5% 50V
C10 1-162-851-11 CERAMIC 0.1uF 16V
C11 1-102-112-00 CERAMIC 330PF 10% 50V
C12 1-126-964-11 ELECT 10uF 20% 50V
C13 1-162-306-11 CERAMIC 0.01uF 20% 16V
C14 1-161-061-11 CERAMIC 0.068uF 10% 50V
C15 1-161-024-00 CERAMIC 0.082uF 10% 25V
C16 1-161-024-00 CERAMIC 0.082uF 10% 25V
C17 1-126-963-11 ELECT 4.7uF 20% 50V
C18 1-126-967-11 ELECT 47uF 20% 16V
C19 1-162-306-11 CERAMIC 0.01uF 20% 16V
C20 1-126-963-11 ELECT 4.7uF 20% 50V
C21 1-126-963-11 ELECT 4.7uF 20% 50V
C22 1-162-306-11 CERAMIC 0.01uF 20% 16V
