Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 63 —
C23 1-161-053-00 CERAMIC 0.015uF 10% 50V
(AEP)
C23 1-161-055-00 CERAMIC 0.022uF 10% 50V
(US, CND)
C24 1-161-053-00 CERAMIC 0.015uF 10% 50V
(AEP)
C24 1-161-055-00 CERAMIC 0.022uF 10% 50V
(US, CND)
C26 1-162-306-11 CERAMIC 0.01uF 20% 16V
C27 1-126-934-11 ELECT 220uF 20% 16V
C44 1-161-051-00 CERAMIC 0.01uF 10% 50V
C45 1-136-177-00 FILM 1uF 5% 50V
C46 1-126-964-11 ELECT 10uF 20% 50V
C47 1-162-306-11 CERAMIC 0.01uF 20% 16V
C48 1-126-964-11 ELECT 10uF 20% 50V
C49 1-162-306-11 CERAMIC 0.01uF 20% 16V
C50 1-162-294-31 CERAMIC 0.001uF 10% 50V
C51 1-162-294-31 CERAMIC 0.001uF 10% 50V
C53 1-162-294-31 CERAMIC 0.001uF 10% 50V
C54 1-102-518-11 CERAMIC 33PF 5% 50V
C55 1-162-199-31 CERAMIC 10PF 5% 50V
C56 1-162-290-31 CERAMIC 470PF 10% 50V
C57 1-162-286-21 CERAMIC 220PF 10% 50V
C58 1-162-306-11 CERAMIC 0.01uF 20% 16V
C59 1-162-306-11 CERAMIC 0.01uF 20% 16V
C62 1-162-294-31 CERAMIC 0.001uF 10% 50V
C63 1-162-306-11 CERAMIC 0.01uF 20% 16V
C64 1-162-198-31 CERAMIC 8.2PF 10% 50V
C65 1-162-282-31 CERAMIC 100PF 10% 50V
C66 1-161-051-00 CERAMIC 0.01uF 10% 50V
C67 1-162-294-31 CERAMIC 0.001uF 10% 50V
C68 1-162-215-31 CERAMIC 47PF 5% 50V
C69 1-162-306-11 CERAMIC 0.01uF 20% 16V
C71 1-162-294-31 CERAMIC 0.001uF 10% 50V
C72 1-162-306-11 CERAMIC 0.01uF 20% 16V
C73 1-136-177-00 FILM 1uF 5% 50V
C74 1-162-282-31 CERAMIC 100PF 10% 50V
C80 1-162-294-31 CERAMIC 0.001uF 10% 50V
C81 1-162-282-31 CERAMIC 100PF 10% 50V
< FILTER >
CF1 1-760-127-11 FILTER, CERAMIC (US, CND)
CF1 1-760-468-11 FILTER, CERAMIC (AEP)
CF2 1-760-127-11 FILTER, CERAMIC (US, CND)
CF2 1-760-468-11 FILTER, CERAMIC (AEP)
CF3 1-760-127-11 FILTER, CERAMIC (US, CND)
CF3 1-760-468-11 FILTER, CERAMIC (AEP)
CF4 1-579-762-11 VIBRATOR, CERAMIC
< COMPOSITION CIRCUIT BLOCK >
CFT1 1-239-173-11 ENCAPSULATED COMPONENT
< CONNECTOR >
* CN1 1-695-374-31 PIN, CONNECTOR (PC BOARD) 13P
CN2 1-536-354-00 POST PIN
< TRIMMER >
CT1 1-141-411-11 CAP, ADJ 20PF
CT2 1-141-411-11 CAP, ADJ 20PF
< DIODE >
D1 8-719-050-72 DIODE KV1370NT
D2 8-719-050-72 DIODE KV1370NT
D3 8-719-050-69 DIODE KV1520N
D8 8-719-991-33 DIODE 1SS133T-77
< FUSE HOLDER >
FH1 1-533-233-21 HOLDER, FUSE
< FILTER >
FL1 1-236-022-11 FILTER, BAND PASS
< IC >
IC1 8-759-386-02 IC TA2008AN
IC3 8-759-333-33 IC BU2614
< COIL >
L2 1-409-905-11 COIL, FM RF
L3 1-501-762-11 ANTENNA, FERRITE-ROD (MW)
L4 1-411-234-21 COIL, AM OSC
L5 1-410-336-11 INDUCTOR 220uH
L7 1-410-521-11 INDUCTOR 100uH
L8 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q1 8-729-115-80 TRANSISTOR BA1A4P
Q2 8-729-115-80 TRANSISTOR BA1A4P
Q3 8-729-115-80 TRANSISTOR BA1A4P
Q4 8-729-115-80 TRANSISTOR BA1A4P
Q15 8-729-422-57 TRANSISTOR UN4111
Q16 8-729-012-83 TRANSISTOR 2SK679A
Q18 8-729-922-66 TRANSISTOR 2SC2410SN
Q19 8-729-106-07 TRANSISTOR 2SK514-H
< RESISTOR >
R1 1-249-441-11 CARBON 100K 5% 1/4W
R2 1-247-887-00 CARBON 220K 5% 1/4W
R3 1-249-431-11 CARBON 15K 5% 1/4W
R4 1-249-429-11 CARBON 10K 5% 1/4W
R6 1-247-887-00 CARBON 220K 5% 1/4W
R7 1-249-411-11 CARBON 330 5% 1/4W
R8 1-247-863-91 CARBON 22K 5% 1/4W
R9 1-249-421-11 CARBON 2.2K 5% 1/4W F
R10 1-249-425-11 CARBON 4.7K 5% 1/4W F
R11 1-247-815-91 CARBON 220 5% 1/4W
R14 1-247-793-91 CARBON 27
R17 1-247-807-31 CARBON 100 5% 1/4W
R25 1-249-429-11 CARBON 10K 5% 1/4W
R26 1-249-425-11 CARBON 4.7K 5% 1/4W F
R27 1-249-429-11 CARBON 10K 5% 1/4W
R28 1-249-429-11 CARBON 10K 5% 1/4W
R29 1-249-415-11 CARBON 680 5% 1/4W F
R30 1-249-412-11 CARBON 390 5% 1/4W F
R35 1-249-417-11 CARBON 1K 5% 1/4W F
R35 1-249-421-11 CARBON 2.2K 5% 1/4W F
TUNER
