Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 64 —
CFD-980
Sony Corporation
Personal A&V Products Company
98A1666-1
Printed in Japan © 1998.1
Published by Quality Engineering Dept.
(Shibaura)
9-923-297-11
R37 1-249-429-11 CARBON 10K 5% 1/4W
R38 1-249-429-11 CARBON 10K 5% 1/4W
R39 1-249-429-11 CARBON 10K 5% 1/4W
R40 1-249-417-11 CARBON 1K 5% 1/4W F
R41 1-249-417-11 CARBON 1K 5% 1/4W F
R42 1-249-425-11 CARBON 4.7K 5% 1/4W F
R43 1-249-437-11 CARBON 47K 5% 1/4W
R46 1-247-863-91 CARBON 22K 5% 1/4W
R55 1-249-421-11 CARBON 2.2K 5% 1/4W F
R56 1-249-407-11 CARBON 150 5% 1/4W F
R57 1-249-399-11 CARBON 33 5% 1/4W F
R58 1-249-411-11 CARBON 330 5% 1/4W
R59 1-249-437-11 CARBON 47K 5% 1/4W
R60 1-249-425-11 CARBON 4.7K 5% 1/4W F
R66 1-249-437-11 CARBON 47K 5% 1/4W
R67 1-249-421-11 CARBON 2.2K 5% 1/4W F
< VIBRATOR >
X1 1-760-130-11 VIBRATOR, CRYSTAL (75kHz)
************************************************************
MISCELLANEOUS
**************
64 1-782-831-11 WIRE PARALLEL (30 CORE)
119 1-692-960-11 SWITCH, PUSH (1KEY)
126 1-452-952-11 MAGNET
129 1-782-832-11 WIRE, PARALLEL (14 CORE)
130 1-782-830-11 WIRE, PARALLEL (16 CORE)
ANT1 1-501-947-11 ANTENNA, TELESCOPIC
L3 1-501-762-11 ANTENNA, FERRITE-ROD (MW)
LCD801 1-801-875-11 DISPLAY PANEL, LIQUID CRYSTAL
M601 1-698-727-11 MOTOR (EG-530-AD-9B)
HE601 1-500-334-11 HEAD, E (TC-238)
HRP601 1-500-333-11 HEAD, R-P (MS15R-AA2N1)
SP101 1-505-731-11 SPEAKER (10CM) (R-CH)
SP201 1-505-731-11 SPEAKER (10CM) (L-CH)
S601 1-762-658-11 SWITCH, LEAF (MSW-1541T)
S602 1-762-819-11 SWITCH, LEAF
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
! 1-475-327-11 ADAPTOR, AC (AC-CD980) (US, CND)
3-861-066-11 MANUAL, INSTRUCTION (US, CND) (ENGLISH)
3-861-066-21 MANUAL, INSTRUCTION (CND) (FRENCH)
! 1-475-328-11 ADAPTOR, AC (AC-CD980) (AEP)
3-861-066-31 MANUAL, INSTRUCTION (AEP)
(ENGLISH/GERMAN)
3-861-066-41 MANUAL, INSTRUCTION (AEP)
(FRENCH/SPANISH)
3-861-066-51 MANUAL, INSTRUCTION (AEP)
(DUTCH/SWEDISH/PORTUGUESE)
3-861-066-61 MANUAL, INSTRUCTION (AEP)
(SWEDISH, DANISH)
3-861-066-71 MANUAL, INSTRUCTION (AEP) (ITALIAN)
1-783-574-11 CORD, CAR BATTERY (DCC-EC9)
* 4-941-548-11 LABEL, CLASS (1) (AEP)
************************************************************
HARDWARE LIST
**************
#1 7-685-648-79 SCREW TAPPING +BV 3 × 12
#2 7-685-647-79 SCREW TAPPING +BV 3 × 10
#3 7-685-646-79 SCREW TAPPING +BV 3 × 8
#4 7-685-104-14 SCREW +P 2 × 6 TYPE2 NON-SLIT
#5 7-685-780-01 SCREW +PTT 2 × 3 (S)
#6 7-685-864-09 SCREW +BVTP 2.6 × 10 (S)
#7 7-685-792-09 SCREW +PTT 2.6 × 6 (S)
#8 7-621-255-15 SCREW +P 2 × 3
#9 7-685-863-01 SCREW +BV 2.6 × 8
#10 7-685-651-79 SCREW TAPPING +B 3 × 20
TUNER
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
