Sony CFD-RS60CP - IC101 Pin Description (Part 3)

45
CFD-RS60CP
92 MDi I Light amount monitor input from the laser diode of optical pick-up block
93 RVSS3 — Ground
94 FNi2 (C) I Main beam (C) input from the optical pick-up block
95 FNi1 (A) I Main beam (A) input from the optical pick-up block
96 FPi2 (D) I Main beam (D) input from the optical pick-up block
97 FPi1 (B) I Main beam (B) input from the optical pick-up block
98 TPi (F) I Sub beam (F) input from the optical pick-up block
99 TNPC O External capacitor connection pin
100 TNi (E) I Sub beam (E) input from the optical pick-up block
Pin No. Pin Name I/O Pin Description
