Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
48
HCD-DC1
R899 1-216-821-11 METAL CHIP 1K 5% 1/16W
< TERMINAL BOARD/JACK >
SJ301 1-694-820-11 TERMINAL BOARD
(SPEAKER IMPEDANCE USE 6-16Ω)
SJ302 1-815-045-11 JACK, PIN 2P (AUDIO IN MD (VIDEO))
< GROUND TERMINAL BOARD >
TH1 1-537-770-21 TERMINAL BOARD, GROUND
TH2 1-537-770-21 TERMINAL BOARD, GROUND
< TUNER UNIT >
TU1 A-4476-414-A TUNER PACK (AEP, UK)
TU1 A-4476-415-A TUNER PACK (EXCEPT AEP, UK)
< VIBRATOR >
X801 1-767-184-11 VIBRATOR, CERAMIC (4.19MHz)
X802 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X803 1-579-242-41 VIBRATOR, CRYSTAL (4.332MHz) (AEP, UK)
**************************************************************
A-4726-695-A POWER BOARD, COMPLETE (AEP, UK)
A-4727-416-A POWER BOARD, COMPLETE (HK, MY, SP)
A-4727-421-A POWER BOARD, COMPLETE (CND, US)
A-4727-599-A POWER BOARD, COMPLETE (MX)
***********************
< CAPACITOR >
C902 1-101-005-00 CERAMIC 22000PF 50V
C903 1-101-005-00 CERAMIC 22000PF 50V
C904 1-101-005-00 CERAMIC 22000PF 50V
C905 1-101-005-00 CERAMIC 22000PF 50V
C906 1-161-494-00 CERAMIC 0.022uF 25V
C907 1-161-494-00 CERAMIC 0.022uF 25V
C908 1-161-494-00 CERAMIC 0.022uF 25V
C909 1-161-494-00 CERAMIC 0.022uF 25V
C910 1-161-494-00 CERAMIC 0.022uF 25V
C911 1-126-947-11 ELECT 47uF 20% 16V
C913 1-161-494-00 CERAMIC 0.022uF 25V
C914 1-161-494-00 CERAMIC 0.022uF 25V
C915 1-161-494-00 CERAMIC 0.022uF 25V
C916 1-161-494-00 CERAMIC 0.022uF 25V
C917 1-126-934-11 ELECT 220uF 20% 10V
C918 1-124-261-00 ELECT 10uF 20% 50V
C920 1-104-666-11 ELECT 220uF 20% 16V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
CN902 1-766-282-11 PIN, CONNECTOR (PC BOARD) 9P
< DIODE >
D902 8-719-902-17 DIODE 1N5401
D903 8-719-902-17 DIODE 1N5401
D904 8-719-902-17 DIODE 1N5401
D905 8-719-902-17 DIODE 1N5401
D906 8-719-046-07 DIODE 2A02M
D907 8-719-046-07 DIODE 2A02M
D908 8-719-046-07 DIODE 2A02M
D909 8-719-046-07 DIODE 2A02M
D910 8-719-991-33 DIODE 1SS133T-77
D911 8-719-991-33 DIODE 1SS133T-77
D912 8-719-991-33 DIODE 1SS133T-77
D913 8-719-991-33 DIODE 1SS133T-77
D915 8-719-109-93 DIODE MTZJ-T-77-6.2B
D917 8-719-991-33 DIODE 1SS133T-77
D918 8-719-109-93 DIODE MTZJ-T-77-6.2B
< FUSE >
0 F901 1-576-374-11 FUSE, GLASS TUBE (DIA. 5) T1.25AL/125V
(CND, MX, US)
0 F901 1-533-464-11 FUSE, GLASS TUBE (DIA. 5) T0.8AL/250V
(AEP, UK)
0 F902 1-533-466-11 FUSE, GLASS TUBE (DIA. 5) T1.25AL/250V
(HK, MY, SP)
0 F903 1-576-375-11 FUSE, GLASS TUBE (DIA. 5) T3.15AL/125V
(CND, MX, US)
0 F903 1-533-468-11 FUSE, GLASS TUBE (DIA. 5) T2AL/250V
(EXCEPT CND, MX, US)
0 F904 1-576-375-11 FUSE, GLASS TUBE (DIA. 5) T3.15AL/125V
(CND, MX, US)
0 F904 1-533-468-11 FUSE, GLASS TUBE (DIA. 5) T2AL/250V
(EXCEPT CND, MX, US)
0 F905 1-533-464-11 FUSE, GLASS TUBE (DIA. 5) T0.8AL/250V
(HK, MY, SP)
< FUSE HOLDER >
FH901 1-533-313-11 HOLDER, FUSE (HK, MY, SP)
FH902 1-533-313-11 HOLDER, FUSE (HK, MY, SP)
FH903 1-533-313-11 HOLDER, FUSE (HK, MY, SP)
FH904 1-533-313-11 HOLDER, FUSE (HK, MY, SP)
FH905 1-533-313-11 HOLDER, FUSE
FH906 1-533-313-11 HOLDER, FUSE
FH907 1-533-313-11 HOLDER, FUSE
FH908 1-533-313-11 HOLDER, FUSE
FH909 1-533-313-11 HOLDER, FUSE (EXCEPT HK, MY, SP)
FH910 1-533-313-11 HOLDER, FUSE (EXCEPT HK, MY, SP)
< LINE FILTER >
LF901 1-424-150-11 TRANSFORMER, LINE FILTER (CND, MX, US)
< TRANSISTOR >
Q901 8-729-028-54 TRANSISTOR KTC3205-Y-AT
Q902 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
< RESISTOR >
R902 1-249-417-11 CARBON 1K 5% 1/4W
R904 1-249-425-11 CARBON 4.7K 5% 1/4W
R905 1-249-437-11 CARBON 47K 5% 1/4W
R909 1-219-237-11 SOLID 3.3M 20% 1/2W
(CND, US)
< RELAY >
0 RY901 1-755-332-11 RELAY
< SWITCH >
0S901 1-786-152-11 SWITCH, SLIDE (VOLTAGE SELECTOR)
(HK, MY, SP)
MAIN POWER
Ver 1.1
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
