Sony CMT-DC1 - Electrical Parts List; Power Board Components; TC Board Miscellaneous

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
49
HCD-DC1
< TRANSFORMER >
0 T901 1-437-251-11 TRANSFORMER, POWER (AEP, UK)
0 T901 1-437-252-11 TRANSFORMER, POWER (CND, MX, US)
0 T901 1-437-253-11 TRANSFORMER, POWER (HK, MY, SP)
0 T902 1-437-248-11 TRANSFORMER, POWER (AEP, UK)
0 T902 1-437-249-11 TRANSFORMER, POWER (CND, MX, US)
0 T902 1-437-250-11 TRANSFORMER, POWER (HK, MY, SP)
**************************************************************
A-4726-692-A SWITCH BOARD, COMPLETE
(EXCEPT CND, MX, US)
A-4727-418-A SWITCH BOARD, COMPLETE (CND, MX, US)
***********************
1-823-226-11 CABLE, FLEXIBLE FLAT (16 CORE)
< CAPACITOR >
C612 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C613 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C614 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C615 1-124-259-11 ELECT 4.7uF 20% 16V
< CONNECTOR >
* CN805 1-565-938-11 SOCKET, CONNECTOR 16P
CN806 1-568-940-11 PIN, CONNECTOR 2P
< DIODE >
D852 8-719-084-70 LED SY3318-V-S1-T (u (CD))
D853 8-719-084-70 LED SY3318-V-S1-T (TUNER/BAND)
D854 8-719-074-42 LED SLR325VR-T31 (DSG)
D855 8-719-084-70 LED SY3318-V-S1-T (Y (TAPE))
D856 8-719-074-42 LED SLR325VR-T31 (CD SYNC)
< IC >
IC802 8-759-827-70 IC NJL64H400A-1
(REMOTE CONTROL RECEIVER)
< COIL >
L601 1-410-993-11 INDUCTOR CHIP 1uH
L602 1-410-993-11 INDUCTOR CHIP 1uH
< TRANSISTOR >
Q852 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q853 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q854 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q855 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q856 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R600 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R653 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R654 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R655 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R656 1-216-820-11 METAL CHIP 820 5% 1/16W
R657 1-216-819-11 METAL CHIP 680 5% 1/16W
R658 1-216-819-11 METAL CHIP 680 5% 1/16W
R659 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R660 1-216-820-11 METAL CHIP 820 5% 1/16W
R661 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R662 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R663 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R667 1-216-845-11 METAL CHIP 100K 5% 1/16W
R668 1-216-845-11 METAL CHIP 100K 5% 1/16W
R675 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R679 1-216-818-11 METAL CHIP 560 5% 1/16W
R680 1-216-818-11 METAL CHIP 560 5% 1/16W
R684 1-216-819-11 METAL CHIP 680 5% 1/16W
R687 1-216-818-11 METAL CHIP 560 5% 1/16W
R691 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R692 1-216-820-11 METAL CHIP 820 5% 1/16W
R698 1-216-818-11 METAL CHIP 560 5% 1/16W
R699 1-216-818-11 METAL CHIP 560 5% 1/16W
< ROTARY ENCODER >
RV801 1-473-392-11 ENCODER, ROTARY (VOLUME)
< SWITCH >
S802 1-786-220-11 SWITCH, KEY BOARD (u)
S803 1-786-220-11 SWITCH, KEY BOARD (x (CD))
S804 1-786-220-11 SWITCH, KEY BOARD (M (CD))
S805 1-786-220-11 SWITCH, KEY BOARD (m (CD))
S806 1-786-220-11 SWITCH, KEY BOARD (Z (CD))
S807 1-786-220-11 SWITCH, KEY BOARD (Y (TAPE))
S808 1-786-220-11 SWITCH, KEY BOARD (x (TAPE))
S809 1-786-220-11 SWITCH, KEY BOARD (M (TAPE))
S810 1-786-220-11 SWITCH, KEY BOARD (m (TAPE))
S811 1-786-220-11 SWITCH, KEY BOARD (X (TAPE))
S812 1-786-220-11 SWITCH, KEY BOARD (CD SYNC)
S813 1-786-220-11 SWITCH, KEY BOARD (TUNER/BAND)
S814 1-786-220-11 SWITCH, KEY BOARD (– (TUNING))
S815 1-786-220-11 SWITCH, KEY BOARD (+ (TUNING))
S816 1-786-220-11 SWITCH, KEY BOARD (FUNCTION)
**************************************************************
A-4726-690-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C402 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C403 1-104-509-11 CERAMIC CHIP 0.018uF 10% 16V
C404 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C405 1-126-934-11 ELECT 220uF 20% 10V
C408 1-126-947-11 ELECT 47uF 20% 10V
C409 1-126-963-11 ELECT 4.7uF 20% 50V
C410 1-126-963-11 ELECT 4.7uF 20% 50V
C412 1-126-961-11 ELECT 2.2uF 20% 50V
C414 1-126-947-11 ELECT 47uF 20% 10V
C415 1-126-947-11 ELECT 47uF 20% 10V
C416 1-126-963-11 ELECT 4.7uF 20% 50V
C417 1-126-963-11 ELECT 4.7uF 20% 50V
C420 1-126-965-11 ELECT 22uF 20% 50V
C422 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C423 1-126-960-11 ELECT 1uF 20% 50V
C424 1-126-960-11 ELECT 1uF 20% 50V
C425 1-126-934-11 ELECT 220uF 20% 16V
C428 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
POWER SWITCH TC
Ver 1.1
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
