Sony CMT-DF1 User Manual

Optional Components
35
GB
Notes
• When playing MP3 files, sound is not output from
the DIGITAL OUT (OPTICAL) jack.
• You can record digital audio from this system only
when DVD function is selected.
• You cannot make a digital recording of a copy
guarded disc using a digital component connected to
this system. Also, playback may not be possible
depending on the connected component.
• When you connect a component that does not support
Dolby Digital or DTS to the DIGITAL OUT
(OPTICAL) jack and output a Dolby Digital or DTS
bit stream, noise may be heard from the connected
component.
1 Connect a digital optical cord.
See “Hooking up optional components”
(page 34).
2 Connect 6 speakers to an AV amplifier
equipped with a decoder.
For the speaker placement, refer to the
operating instructions supplied with the
connected amplifier.
3 Press SETUP in stop mode.
The Setup Menu appears.
4 Press < or , repeatedly to select
“Audio Setup Page,” then press
ENTER.
5 Press M or m repeatedly to select
“SPDIF Setup,” then press ENTER.
“SPDIF Output” appears.
6 Press ENTER.
7 Press M or m repeatedly to select
“SPDIF/RAW,” then press ENTER.
8 Press SETUP to turn off the Setup
Menu.
9 Switch the output to 5.1 channel Dolby
Digital sound or 5.1 channel DTS
sound.
See “Changing the sound” (page 20).
Enjoying the 5.1 channel
sound with the optional
amplifier

Sony CMT-DF1 Specifications

General

Bass reflex	Yes
Speaker type	1-way
RMS rated power	10 W
Number of speakers	2
Mid-range driver diameter	100 mm
Total Harmonic Distortion (THD)	10 %
Type	Home audio micro system
Cassette deck	No
Product color	Gray
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Supported radio bands	AM, FM
Preset stations quantity	40
Display type	LCD
Speaker depth	187 mm
Speaker width	145 mm
Speaker height	212 mm
Video recording	-
Apple docking compatibility	Not supported
Headphone outputs	1
Power source	AC

Weight and Dimensions

Depth	201 mm
Width	169 mm
Height	218 mm
