44
GB
Amplifier section
European and Russian models:
DIN power output (rated): 3.6 + 3.6 watts (4 ohms at
1 kHz, DIN)
Continuous RMS power output (reference):
5 + 5 watts (4 ohms at
1 kHz, 10% THD)
Music power output (reference):
8 + 8 watts (4 ohms at
1 kHz, 10% THD)
Other models:
The following measured at AC 120 V, 220 V, 240 V,
50/60 Hz
DIN power output (rated): 3.6 + 3.6 watts
(4 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
5 + 5 watts
(4 ohms at 1 kHz, 10%
THD)
Inputs
MIC (monaural mini jack):sensitivity 1.5 mV,
impedance 10 kilohms
Outputs
VIDEO OUT (phono jack):
max. output level
1 Vp-p, unbalanced, Sync
negative, load impedance
75 ohms
S VIDEO OUT (4-pin/mini-DIN jack):
Y: 1 Vp-p, unbalanced,
Sync negative,
C: 0.286 Vp-p, load
impedance 75 ohms
COMPONENT VIDEO OUT:
Y: 1 Vp-p, 75 ohms
P
B, PR: 0.7 Vp-p, 75 ohms
DIGITAL OUT (OPTICAL) (Square optical connector
jack, rear panel)
Wavelength 660 nm
PHONES (stereo mini jack):
accepts headphones of
8 ohms or more
SPEAKER: accepts impedance of
4 ohms
Disc player section
System Compact disc and digital
audio and video system
Laser Laser Diode Properties
• Emission duration:
continuous
• Laser Output*:
Less than 1,000 µW
* This output is the value
measurement at a
distance of 200mm from
the objective lens surface
on the Optical Pick-up
Block with 7mm
aperture.
Semiconductor laser
(DVD: λ=650 nm,
CD: λ=790 nm)
Frequency response DVD (PCM 48 kHz):
2 Hz – 22 kHz (±1 dB)
CD: 2 Hz – 20 kHz (±1 dB)
Tape deck section
Recording system 4-track 2-channel stereo
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range 87.5 – 108.0 MHz
(50 kHz step)
Antenna FM lead antenna
Antenna terminals 75 ohms unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range
Canadian model: 530 – 1,710 kHz
Other models: 531 – 1,602 kHz
Antenna AM loop antenna
Antenna terminals External antenna terminal
Intermediate frequency 450 kHz
Specifications
