Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
103
CX-JTD8
0 R261 1-212-881-11 FUSIBLE 100 5% 1/4W F
R271 1-249-441-11 CARBON 100K 5% 1/4W
R272 1-249-441-11 CARBON 100K 5% 1/4W
0 R280 1-215-888-00 METAL OXIDE 220 5% 2W F
R281 1-260-076-11 CARBON 10 5% 1/2W
R282 1-260-076-11 CARBON 10 5% 1/2W
R283 1-260-076-11 CARBON 10 5% 1/2W
R284 1-260-076-11 CARBON 10 5% 1/2W
R285 1-249-437-11 CARBON 47K 5% 1/4W
R286 1-249-437-11 CARBON 47K 5% 1/4W
R287 1-249-429-11 CARBON 10K 5% 1/4W
R288 1-249-437-11 CARBON 47K 5% 1/4W
R289 1-249-429-11 CARBON 10K 5% 1/4W
R290 1-249-429-11 CARBON 10K 5% 1/4W
R291 1-260-105-11 CARBON 3.3K 5% 1/2W
R292 1-260-105-11 CARBON 3.3K 5% 1/2W
R301 1-249-441-11 CARBON 100K 5% 1/4W
R302 1-249-441-11 CARBON 100K 5% 1/4W
R924 1-249-417-11 CARBON 1K 5% 1/4W
< RELAY >
RY281 1-515-920-11 RELAY
< THERMISTOR >
TH201 1-807-796-11 THERMISTOR
< TERMINAL >
TM201 1-694-677-12 TERMINAL BOARD (4P) (FRONT SPEAKER)
**************************************************************
1-689-683-11 HEADPHONE JACK BOARD
**********************
< CAPACITOR >
C507 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
* CN104 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
* CN503 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D503 8-719-988-61 DIODE 1SS355TE-17
D504 8-719-988-61 DIODE 1SS355TE-17
< RESISTOR >
FB503 1-216-166-00 RES-CHIP 47 5% 1/8W
FB504 1-216-166-00 RES-CHIP 47 5% 1/8W
< JACK >
J502 1-793-829-11 JACK, HEADPHONE (PHONES)
**************************************************************
A-4749-158-A I-BASS BOARD, COMPLETE
**********************
< CAPACITOR >
C315 1-126-963-11 ELECT 4.7uF 20% 50V
C316 1-126-963-11 ELECT 4.7uF 20% 50V
C329 1-126-963-11 ELECT 4.7uF 20% 50V
C330 1-126-963-11 ELECT 4.7uF 20% 50V
C340 1-126-947-11 ELECT 47uF 20% 16V
C341 1-126-947-11 ELECT 47uF 20% 16V
C367 1-136-169-00 FILM 0.22uF 5% 50V
C382 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C383 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C384 1-164-373-11 CERAMIC CHIP 0.033uF 25V
C385 1-164-373-11 CERAMIC CHIP 0.033uF 25V
C396 1-136-169-00 FILM 0.22uF 5% 50V
C400 1-128-551-11 ELECT 22uF 20% 25V
C491 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C492 1-126-960-11 ELECT 1uF 20% 50V
< IC >
IC303 6-704-074-01 IC NJM2156M (TE2)
< TRANSISTOR >
Q314 8-729-045-62 FET 2SK2158-T2B
Q315 8-729-045-62 FET 2SK2158-T2B
Q316 8-729-045-62 FET 2SK2158-T2B
Q317 8-729-045-62 FET 2SK2158-T2B
Q318 8-729-045-62 FET 2SK2158-T2B
Q319 8-729-045-62 FET 2SK2158-T2B
Q320 8-729-045-62 FET 2SK2158-T2B
Q323 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q327 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q328 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q329 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q330 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q331 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q332 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q333 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q491 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q492 8-729-045-62 FET 2SK2158-T2B
< RESISTOR >
R300 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R327 1-216-833-11 METAL CHIP 10K 5% 1/10W
R328 1-216-833-11 METAL CHIP 10K 5% 1/10W
R329 1-216-833-11 METAL CHIP 10K 5% 1/10W
R330 1-216-833-11 METAL CHIP 10K 5% 1/10W
R331 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R332 1-216-835-11 METAL CHIP 15K 5% 1/10W
R333 1-216-833-11 METAL CHIP 10K 5% 1/10W
R334 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R335 1-216-842-11 METAL CHIP 56K 5% 1/10W
R336 1-216-836-11 METAL CHIP 18K 5% 1/10W
R337 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R338 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R339 1-216-821-11 METAL CHIP 1K 5% 1/10W
R340 1-216-833-11 METAL CHIP 10K 5% 1/10W
FRONT AMP HEADPHONE JACK I-BASS
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
