CX-JTD8
16
3-12. TRANS BOARD
3-13. MB03 BOARD
3
four screws
(ITC+4-10R)
2
earth lug
4
trans board
1
screw
(BVTT3
×
6)
4
four screws
(BVTT3
×
6)
6
MB03 board
3
connector
(CN102)
5
heat sink
1
wire (flat type) (29 core)
(CN501)
2
wire (flat type)
(17 core)(CN105)
