CX-JTD8
20
3-20. OPTICAL TRAVERSE UNIT (DBU-1)
7
Insulator
2
8
Insulator (HRC)
6
Insulator
(HRC)
0
Holder (DBU) assy
4
Step
screw (M)
5
Step
screw (M)
1
Floating
screw (PTPWH M2.6
)
3
Step
screw (M)
9
Optical traverse unit (DBU-1)
