Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
107
CX-JTD8
Q704 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q705 8-729-905-35 TRANSISTOR 2SC4081T106R
Q706 8-729-905-35 TRANSISTOR 2SC4081T106R
Q707 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q708 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q709 8-729-905-35 TRANSISTOR 2SC4081T106R
Q710 8-729-905-35 TRANSISTOR 2SC4081T106R
Q713 8-729-026-68 TRANSISTOR 2SD2525 (TP)
Q714 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q719 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q721 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q723 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q724 8-729-028-73 TRANSISTOR DTA114EUA-T106
< RESISTOR >
R102 1-216-841-11 METAL CHIP 47K 5% 1/10W
R104 1-216-821-11 METAL CHIP 1K 5% 1/10W
R105 1-216-845-11 METAL CHIP 100K 5% 1/10W
R109 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R111 1-216-833-11 METAL CHIP 10K 5% 1/10W
R116 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R117 1-216-833-11 METAL CHIP 10K 5% 1/10W
R119 1-216-818-11 METAL CHIP 560 5% 1/10W
0 R120 1-215-891-11 METAL OXIDE 680 5% 2W F
R121 1-216-821-11 METAL CHIP 1K 5% 1/10W
R122 1-216-821-11 METAL CHIP 1K 5% 1/10W
R123 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R124 1-216-821-11 METAL CHIP 1K 5% 1/10W
R125 1-216-845-11 METAL CHIP 100K 5% 1/10W
R126 1-216-833-11 METAL CHIP 10K 5% 1/10W
R127 1-216-818-11 METAL CHIP 560 5% 1/10W
R129 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0 R130 1-215-891-11 METAL OXIDE 680 5% 2W F
R131 1-216-821-11 METAL CHIP 1K 5% 1/10W
R132 1-216-821-11 METAL CHIP 1K 5% 1/10W
R134 1-216-805-11 METAL CHIP 47 5% 1/10W
R137 1-216-833-11 METAL CHIP 10K 5% 1/10W
R138 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R139 1-216-845-11 METAL CHIP 100K 5% 1/10W
R140 1-216-846-11 METAL CHIP 120K 5% 1/10W
R141 1-216-845-11 METAL CHIP 100K 5% 1/10W
R146 1-216-837-11 METAL CHIP 22K 5% 1/10W
R155 1-216-845-11 METAL CHIP 100K 5% 1/10W
R158 1-216-864-11 SHORT CHIP 0
R159 1-216-821-11 METAL CHIP 1K 5% 1/10W
R160 1-216-864-11 SHORT CHIP 0
R162 1-216-864-11 SHORT CHIP 0
R163 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R165 1-216-864-11 SHORT CHIP 0
R171 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R174 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R176 1-216-845-11 METAL CHIP 100K 5% 1/10W
R177 1-216-853-11 METAL CHIP 470K 5% 1/10W
R178 1-216-857-11 METAL CHIP 1M 5% 1/10W
R179 1-216-845-11 METAL CHIP 100K 5% 1/10W
R183 1-216-833-11 METAL CHIP 10K 5% 1/10W
R184 1-216-837-11 METAL CHIP 22K 5% 1/10W
R185 1-216-837-11 METAL CHIP 22K 5% 1/10W
R201 1-216-821-11 METAL CHIP 1K 5% 1/10W
R202 1-216-845-11 METAL CHIP 100K 5% 1/10W
R203 1-216-821-11 METAL CHIP 1K 5% 1/10W
R204 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R251 1-216-821-11 METAL CHIP 1K 5% 1/10W
R252 1-216-845-11 METAL CHIP 100K 5% 1/10W
R253 1-216-821-11 METAL CHIP 1K 5% 1/10W
R254 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R271 1-216-864-11 SHORT CHIP 0
R301 1-216-841-11 METAL CHIP 47K 5% 1/10W
R302 1-216-817-11 METAL CHIP 470 5% 1/10W
R303 1-216-833-11 METAL CHIP 10K 5% 1/10W
R304 1-216-833-11 METAL CHIP 10K 5% 1/10W
R305 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R306 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R307 1-216-841-11 METAL CHIP 47K 5% 1/10W
R309 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R310 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R311 1-216-841-11 METAL CHIP 47K 5% 1/10W
R312 1-216-857-11 METAL CHIP 1M 5% 1/10W
R313 1-216-833-11 METAL CHIP 10K 5% 1/10W
R314 1-216-819-11 METAL CHIP 680 5% 1/10W
R320 1-216-833-11 METAL CHIP 10K 5% 1/10W
R321 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R322 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R323 1-216-841-11 METAL CHIP 47K 5% 1/10W
R330 1-216-857-11 METAL CHIP 1M 5% 1/10W
R331 1-216-821-11 METAL CHIP 1K 5% 1/10W
R332 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R341 1-216-809-11 METAL CHIP 100 5% 1/10W
R342 1-216-809-11 METAL CHIP 100 5% 1/10W
R351 1-216-841-11 METAL CHIP 47K 5% 1/10W
R352 1-216-817-11 METAL CHIP 470 5% 1/10W
R353 1-216-833-11 METAL CHIP 10K 5% 1/10W
R354 1-216-833-11 METAL CHIP 10K 5% 1/10W
R355 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R356 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R357 1-216-841-11 METAL CHIP 47K 5% 1/10W
R359 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R360 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R361 1-216-841-11 METAL CHIP 47K 5% 1/10W
R362 1-216-857-11 METAL CHIP 1M 5% 1/10W
R363 1-216-833-11 METAL CHIP 10K 5% 1/10W
R364 1-216-819-11 METAL CHIP 680 5% 1/10W
R371 1-216-864-11 SHORT CHIP 0
R372 1-216-864-11 SHORT CHIP 0
R373 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R374 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R375 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R376 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R377 1-216-864-11 SHORT CHIP 0
R381 1-216-845-11 METAL CHIP 100K 5% 1/10W
R382 1-216-845-11 METAL CHIP 100K 5% 1/10W
R383 1-216-845-11 METAL CHIP 100K 5% 1/10W
R384 1-216-845-11 METAL CHIP 100K 5% 1/10W
R385 1-216-845-11 METAL CHIP 100K 5% 1/10W
R386 1-216-845-11 METAL CHIP 100K 5% 1/10W
MAIN
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
