Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
115
CX-JTD8
MB03 MICON-KEY
R949 1-216-864-11 SHORT CHIP 0
R958 1-216-801-11 METAL CHIP 22 5% 1/10W
R962 1-216-833-11 METAL CHIP 10K 5% 1/10W
R964 1-216-833-11 METAL CHIP 10K 5% 1/10W
R970 1-216-864-11 SHORT CHIP 0
R971 1-216-864-11 SHORT CHIP 0
R973 1-216-864-11 SHORT CHIP 0
R974 1-216-864-11 SHORT CHIP 0
R975 1-216-833-11 METAL CHIP 10K 5% 1/10W
R976 1-216-864-11 SHORT CHIP 0
R978 1-216-833-11 METAL CHIP 10K 5% 1/10W
R984 1-216-833-11 METAL CHIP 10K 5% 1/10W
R988 1-216-864-11 SHORT CHIP 0
R990 1-216-864-11 SHORT CHIP 0
R991 1-216-864-11 SHORT CHIP 0
R992 1-216-864-11 SHORT CHIP 0
R994 1-216-864-11 SHORT CHIP 0
R995 1-216-864-11 SHORT CHIP 0
R996 1-216-864-11 SHORT CHIP 0
R997 1-216-864-11 SHORT CHIP 0
R998 1-216-864-11 SHORT CHIP 0
R1000 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1001 1-216-864-11 SHORT CHIP 0
R1101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1201 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1202 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1301 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1303 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1304 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1801 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1802 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1803 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R5555 1-216-864-11 SHORT CHIP 0
R9980 1-216-864-11 SHORT CHIP 0
R9981 1-216-864-11 SHORT CHIP 0
R9986 1-216-864-11 SHORT CHIP 0
R9987 1-216-864-11 SHORT CHIP 0
R9988 1-216-864-11 SHORT CHIP 0
R9993 1-216-864-11 SHORT CHIP 0
R9994 1-216-864-11 SHORT CHIP 0
R9998 1-216-864-11 SHORT CHIP 0
R9999 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB10 1-233-388-11 RES, NETWORK 68 (3216)
RB11 1-233-388-11 RES, NETWORK 68 (3216)
RB12 1-233-388-11 RES, NETWORK 68 (3216)
RB13 1-233-388-11 RES, NETWORK 68 (3216)
RB14 1-233-388-11 RES, NETWORK 68 (3216)
RB15 1-233-388-11 RES, NETWORK 68 (3216)
RB16 1-233-388-11 RES, NETWORK 68 (3216)
RB17 1-233-388-11 RES, NETWORK 68 (3216)
RB18 1-234-524-21 RES, CHIP NETWORK 33
RB19 1-234-524-21 RES, CHIP NETWORK 33
RB20 1-234-524-21 RES, CHIP NETWORK 33
RB21 1-234-524-21 RES, CHIP NETWORK 33
RB202 1-234-523-21 RES, CHIP NETWORK 0 (3216)
RB203 1-234-523-21 RES, CHIP NETWORK 0 (3216)
RB204 1-234-523-21 RES, CHIP NETWORK 0 (3216)
< VIBRATOR >
X901 1-781-945-21 VIBRATOR, CERAMIC (20MHz)
X902 1-795-630-11 VIBRATOR, CRYSTAL (27MHz)
**************************************************************
A-4749-170-A MICON-KEY BOARD, COMPLETE
*************************
4-248-122-01 GUIDE, FL
< CAPACITOR >
C100 1-104-665-11 ELECT 100uF 20% 10V
C101 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C125 1-104-665-11 ELECT 100uF 20% 10V
C191 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C192 1-104-665-11 ELECT 100uF 20% 10V
C193 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C194 1-126-967-11 ELECT 47uF 20% 50V
C195 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C197 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C206 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C207 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C208 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C209 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C225 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C301 1-126-961-11 ELECT 2.2uF 20% 50V
C333 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C334 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C335 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C336 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C337 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C338 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C339 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C340 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C341 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C342 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C343 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C344 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C353 1-126-961-11 ELECT 2.2uF 20% 50V
C401 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C402 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C403 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C404 1-126-957-11 ELECT 0.22uF 20% 50V
C405 1-126-964-11 ELECT 10uF 20% 50V
C406 1-126-934-11 ELECT 220uF 20% 10V
C407 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C408 1-126-956-91 ELECT 0.1uF 20% 50V
C409 1-126-964-11 ELECT 10uF 20% 50V
C410 1-126-965-11 ELECT 22uF 20% 50V
C411 1-115-414-11 CERAMIC CHIP 820PF 5% 25V
C412 1-126-960-11 ELECT 1uF 20% 50V
C420 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C421 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C422 1-164-473-11 CERAMIC CHIP 820PF 5% 50V
